Troubleshooting 12-15
12037
Open Circuit
CP, Flashing
red
Soft
The fast flux up current is less
than 50% of commanded.
Make sure the motor is properly connected.
Refer to the Understanding Precharge and Ridethrough
Faults section for more information.
If you do not want this condition to be reported as a fault,
change bit 5 in Fault Select 1 (parameter 20) to 0.
12064
RidethruTime
CP, Solid
green
Warning
There was a drop of 150V and
power did not return within 2
seconds.
Check the incoming power and fuses.
Refer to the Understanding Precharge and Ridethrough
Faults section for more information.
If you do not want this condition to be reported as a
warning, change bit 0 in Warning Select 1
(parameter 21) to 0.
12065
Prechrg Time
CP, Solid
green
Warning
The precharge function could not
complete within 30 seconds.
Refer to the Understanding Precharge and Ridethrough
Faults section for more information.
If you do not want this condition to be reported as a
warning, change bit 1 in Warning Select 1
(parameter 21) to 0.
12066
Bus Drop
CP, Solid
green
Warning
The bus voltage dropped 150V
below the bus tracker voltage.
Monitor the incoming AC line for low voltage or line
power interruption.
Refer to the Understanding Precharge and Ridethrough
Faults section for more information.
If you do not want this condition to be reported as a
warning, change bit 2 in Warning Select 1
(parameter 21) to 0.
12067
Bus Undervlt
CP, Solid
green
Warning
The DC bus voltage fell below the
minimum value (388V DC at
460V AC input).
Monitor the incoming AC line for low voltage or line
power interruption.
Refer to the Understanding Precharge and Ridethrough
Faults section for more information.
If you do not want this condition to be reported as a
warning, change bit 3 in Warning Select 1
(parameter 21) to 0.
12068
Bus Cycle>5
CP, Solid
green
Warning
At least 5 ridethrough cycles
have occurred within a 20 second
period. This indicates a converter
problem or a problem with the
incoming power.
Monitor the incoming AC line for low voltage or line
power interruption.
Refer to the Understanding Precharge and Ridethrough
Faults section for more information.
If you do not want this condition to be reported as a
warning, change bit 4 in Warning Select 1
(parameter 21) to 0.
12069
Open Circuit
CP, Solid
green
Warning
The fast flux up current is less
than 50% of commanded.
Make sure the motor is properly connected.
Refer to the Understanding Precharge and Ridethrough
Faults section for more information.
If you do not want this condition to be reported as a
warning, change bit 5 in Warning Select 1
(parameter 21) to 0.
13000
HW Malfunction
CP, Solid red Hard
A hardware malfunction
occurred.
Recycle the power. If the fault does not clear, replace the
board.
13001
HW Malfunction
CP, Solid red Hard
A hardware malfunction
occurred.
Recycle the power. If the fault does not clear, replace the
board.
13002
HW Malfunction
CP, Solid red Hard
A hardware malfunction
occurred.
Recycle the power. If the fault does not clear, replace the
board.
13003
HW Malfunction
CP, Solid red Hard
A hardware malfunction
occurred.
Recycle the power. If the fault does not clear, replace the
board.
13004
HW Malfunction
CP, Solid red Hard
A hardware malfunction
occurred.
Recycle the power. If the fault does not clear, replace the
board.
Fault Code
and Text
LED
Information
Fault
Type
Description Suggested Action
