Troubleshooting 12-13
06074
SP 2 Timeout
VP, Flashing
green
Warning
The SCANport adapter at port 2
has been disconnected and the
logic mask bit for port 2 is set (1).
If the adapter was not intentionally disconnected:
• Check the wiring to the SCANport adapters.
• Replace wiring, SCANport expander, SCANport
adapters, and main control board.
• Complete drive, if required.
If you do not want this condition to be reported as a
warning, change bit 10 in Warning Select 1
(parameter 21) to 0.
06075
SP 3 Timeout
VP, Flashing
green
Warning
The SCANport adapter at port 3
has been disconnected and the
logic mask bit for port 3 is set (1).
If the adapter was not intentionally disconnected:
• Check the wiring to the SCANport adapters.
• Replace wiring, SCANport expander, SCANport
adapters, and main control board.
• Complete drive, if required.
If you do not want this condition to be reported as a
warning, change bit 11 in Warning Select 1
(parameter 21) to 0.
06076
SP 4 Timeout
VP, Flashing
green
Warning
The SCANport adapter at port 4
has been disconnected and the
logic mask bit for port 4 is set (1).
If the adapter was not intentionally disconnected:
• Check the wiring to the SCANport adapters.
• Replace wiring, SCANport expander, SCANport
adapters, and main control board.
• Complete drive, if required.
If you do not want this condition to be reported as a
warning, change bit 12 in Warning Select 1
(parameter 21) to 0.
06077
SP 5 Timeout
VP, Flashing
green
Warning
The SCANport adapter at port 5
has been disconnected and the
logic mask bit for port 5 is set (1).
If the adapter was not intentionally disconnected:
• Check the wiring to the SCANport adapters.
• Replace wiring, SCANport expander, SCANport
adapters, and main control board.
• Complete drive, if required.
If you do not want this condition to be reported as a
warning, change bit 13 in Warning Select 1
(parameter 21) to 0.
06078
SP 6 Timeout
VP, Flashing
green
Warning
The SCANport adapter at port 6
has been disconnected and the
logic mask bit for port 6 is set (1).
If the adapter was not intentionally disconnected:
• Check the wiring to the SCANport adapters.
• Replace wiring, SCANport expander, SCANport
adapters, and main control board.
• Complete drive, if required.
If you do not want this condition to be reported as a
warning, change bit 14 in Warning Select 1
(parameter 21) to 0.
06079
SP Error
VP, Flashing
green
Warning
SCANport communications have
been interrupted.
If the adapter was not intentionally disconnected:
• Check the amount of noise on the system.
• Check the wiring to the SCANport adapters.
• Replace wiring, SCANport expander, SCANport
adapters, and main control board.
• Complete drive, if required.
If you do not want this condition to be reported as a
warning, change bit 15 in Warning Select 1
(parameter 21) to 0.
Fault Code
and Text
LED
Information
Fault
Type
Description Suggested Action
