Configuring Faults and Warnings Group 1
You can configure which of the following faults you want to trip the
drive by using Fault Select 1 (parameter 20) and Warning Select 1
(parameter 21). Fault Select 1 and Warning Select 1 both have the
following bit definitions:
Bits 6 and 7 are reserved.
For each condition that you want the drive to fault on, set the
corresponding bit in Fault Select 1. When the drive trips on a
condition that you set to fault the drive, how the drive reacts depends
on which condition occurred.
For bits 0 through 5:
• The red CP light turns on.
• The motor coasts to a stop.
For bits 8 through 14:
• The red VP light turns on.
• The motor stops according to how bits 1 – 3 in Logic Options
(parameter 17) are set.
file:
Fault Setup
group:
Fault Config
This bit: With this text: Is defined as:
0 RidethruTime A bus ridethrough timeout occurred.
1 Prechrg Time A precharge timeout occurred.
2 Bus Drop
A bus voltage drop of 150V below the bus tracker
voltage. This is covered in detail later in this chapter.
3 Bus Undervlt
A bus voltage drop to a level below the value set in Line
Undervolts (parameter 27).
4 Bus Cycles>5
More than 5 ridethroughs occurred within a 20 second
period.
5 Open Circuit
The fast flux up current is less than 50% of
commanded.
8 mA Input A loss of input connection after it was established.
9 SP 1 Timeout A communication loss with SCANport device 1.
10 SP 2 Timeout A communication loss with SCANport device 2.
11 SP 3 Timeout A communication loss with SCANport device 3.
12 SP 4 Timeout A communication loss with SCANport device 4.
13 SP 5 Timeout A communication loss with SCANport device 5.
14 SP 6 Timeout A communication loss with SCANport device 6.
15 SP Error Too many errors have occurred in the communications.
If this bit is set: Then this stop type is used:
1 Coast
2 Current limit
3 Ramp
