Troubleshooting 12-3
Faults fall into three basic categories:
Faults are annunciated on the Human Interface Module (HIM) at the
time they occur. Warnings are not annunciated on the HIM.
To help troubleshoot your 1336 IMPACT drive, the drive logs any
faults or warnings in either the fault or warning queue. The faults and
warnings that are contained in the queues are of either a configurable
type or a non-configurable type.
Several bit-encoded parameters are also available to help troubleshoot
your drive. These parameters are covered later in this chapter and in
the auto-tuning chapter. When viewing these parameters from a HIM,
you should understand how the HIM displays the bits.
When the appropriate parameter is displayed, you will see two rows
of 8 bits represented by zeros and ones. The top row contains (from
left to right) bits 15 through bit 8, and the bottom row contains bits 7
through bit 0.
Refer to Appendix C, Using the Human Interface Module (HIM), for
additional information.
This type
of fault:
Has the following definition:
To remove this fault,
you need to:
Hard
Trips the drive causing it to stop.
You cannot regain control until you
reset the drive.
Perform a Drive Reset command or
cycle drive power.
Soft Trips the drive causing it to stop.
1. Address the condition that
caused the fault.
2. Perform a Clear Faults
command.
Warning
Indicates an undesirable condition.
The drive will not stop.
1. Address the condition that
caused the warning.
2. Perform a Clear Faults
command.
This fault type: Refers to faults that you:
Configurable
Can set up to either trip the drive or provide only a visual
warning while the drive continues to operate.
Non-configurable
Cannot disable. These faults are the result of a condition
that could damage the drive if allowed to persist.
You can reset the faults by pressing the stop button on the HIM.
To: Press this key:
Display the enum (text definition) for bit 0 Select
Continue scrolling through the bits Select for each bit
Return to the parameter Escape
