11-84 Parameters
294
Step 16 Speed
Parameter 294 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 294
File:group Profile Test Data
Parameter type Setup
Display rpm
Factory default +0.0 rpm
Minimum value -8 x base sp
Maximum value +8 x base sp
Conversion 4096 = base motor speed
295
Step 16 Value
Parameter 295 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 =1.0 units
TB Input Step: dependent on [L Option Mode Sel]. See P241
Parameter number 295
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0, 0, 0.0
Minimum value 0.0, 0,0.0
Maximum value 3276.7, 5, 32767.7
Conversion 10=1.0 sec., xTBin, 10 = 1 unit
296
Step 16 Type
Parameter 296 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P294 for time in P295.
2 = TB3 Input Step, operate at speed shown in P294 until this
input goes true.
3 = Encoder Step, operate at speed shown in P294 for units in
P295.
Parameter number 296
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion
