User Manual V 1-4.XX User guide

Parameters 11-83
288
Step 14 Speed
Parameter 288 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 288
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base sp
Maximum value +8 x base sp
Conversion 4096 = base sp
289
Step 14 Value
Parameter 289 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 = 1.0 units
TB Input Step: dependent on [L Option Mode Sel]. See P241
Parameter number 289
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 10=1.0 sec., x TBin, 10 = 1 unit
290
Step 14 Type
Parameter 290 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P288 for time in P289.
2 = TB3 Input Step, operate at speed shown in P288 until this
input goes true.
3 = Encoder Step, operate at speed shown in P288 for units in
P289.
Parameter number 290
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion None
291
Step 15 Speed
Parameter 291 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 291
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base sp
Maximum value +8 x base sp
Conversion 4096 = base sp
292
Step 15 Value
Parameter 292 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 = 1.0 units
TB Input Step: dependent on [L Option Mode Sel]. See P241.
Parameter number 292
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 10=1.0 sec., x TBin, 10 = 1 unit
293
Step 15 Type
Parameter 293 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P291 for time in P292.
2 = TB3 Input Step, operate at speed shown in P291 until this
input goes true.
3 = Encoder Step, operate at speed shown in P291 for units in
P292.
Parameter number 293
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion None
