Parameters 11-81
276
Step 10 Speed
Parameter 276 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 276
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default 0.00 rpm
Minimum value -8 x base speed
Maximum value +8 x base speed
Conversion
277
Step 10 Value
Parameter 277 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 = 1.0 units
TB Input Step: dependent on [L Option Mode Sel] See P241
Parameter number 277
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 10=1.0 sec., x TBin, 10 = 1 unit
278
Step 10 Type
Parameter 278 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P276 for time in P277.
2 = TB3 Input Step, operate at speed shown in P276 until this
input goes true. See P241.
3 = Encoder Step, operate at speed shown in P276 for units in
P277.
Parameter number 278
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion
279
Step 11 Speed
Parameter 279 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 279
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default 0.00 rpm
Minimum value -8 x base speed
Maximum value +8 x base speed
Conversion 4096 = base sp
280
Step 11 Value
Parameter 280 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 = 1.0 units
TB Input Step: dependent on [L Option Mode Sel]. See P241
Parameter number 280
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 10=1.0 sec., x TBin, 10 = 1 unit
281
Step 11 Type
Parameter 281 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P279 for time in P280.
2 = TB3 Input Step, operate at speed shown in P279 until this
input goes true.
3 = Encoder Step, operate at speed shown in P279 for units in
P280.
Parameter number 281
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion
