11-80 Parameters
270
Step 8 Speed
Parameter 270 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 270
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base speed
Maximum value +8 x base speed
Conversion 4096 = Base Motor Speed
271
Step 8 Value
Parameter 271 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 = 1.0 units
TB Input Step: dependent on [L Option Mode Sel]. See P241
Parameter number 271
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 10=1.0 sec., x TBin, 10 = 1 unit
272
Step 8 Type
Parameter 272 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P270 for time in P271.
2 = TB3 Input Step, operate at speed shown in P270 until this
input goes true.
3 = Encoder Step, operate at speed shown in P270 for units in
P271.
Parameter number 272
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion
273
Step 9 Speed
Parameter 273 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 273
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base speed
Maximum value +8 x base speed
Conversion 4096 = Base Motor Speed
274
Step 9 Value
Parameter 274 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 = 1.0 units
TB Input Step: dependent on [L Option Mode Sel]. See P241
Parameter number 274
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 10=1.0 sec., x TBib, 10 = 1 unit
275
Step 9 Type
Parameter 275 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P273 for time in P274.
2 = TB3 Input Step, operate at speed shown in P273 until this
input goes true.
3 = Encoder Step, operate at speed shown in P273 for units in
P274.
Parameter number 275
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion
