User Manual V 1-4.XX User guide

11-78 Parameters
258
Step 4 Speed
Parameter 258 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 258
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base speed
Maximum value +8 x base speed
Conversion 4096 = Base Motor Speed
259
Step 4 Value
Parameter 259 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 10 = 1.0 units
TB Input Step: dependent on [L Option Mode Sel]. See P241.
Parameter number 259
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 0=1.0 sec., x TBin, 10 = 1 unit
260
Step 4 Type
Parameter 260 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P258 for time in P259.
2 = TB3 Input Step, operate at speed shown in P258 until this
input goes true.
3 = Encoder Step, operate at speed shown in P258 for units in
P259.
Parameter number 260
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion
261
Step 5 Speed
Parameter 261 sets the rpm value for this step. (Scaling: 4096 =
Base Speed)
Parameter number 261
File:group Profile Test Data
Parameter type Setup
Display +/- x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base speed
Maximum value +8 x base speed
Conversion 4096 = Base Motor Speed
262
Step 5 Value
Parameter 262 sets the time in seconds for time steps, the
counts in units for encoder steps, and the TB3 input to trigger on
for TB Input steps. Scaling:
Time Step: 10 x desired value (10 = 1.0 sec)
Encoder Step: 1 = 1 revolution
TB Input Step: dependent on [L Option Mode Sel]. See P241.
Parameter number 262
File:group Profile Test Data
Parameter type Setup
Display x.xS, x, x.x units
Factory default 0.0,0, 0.0
Minimum value 0.0,0, 0.0
Maximum value 3276.7, 5, 3276.7
Conversion 0=1.0 sec., x TBin, 10 = 1 unit
263
Step 5 Type
Parameter 263 selects the type of step to be used
0 = Not Used (This forces an End Action)
1 = Time Step, operate at speed shown in P261 for time in P262.
2 = TB3 Input Step, operate at speed shown in P261 until P262
input goes true.
3 = Encoder Step, operate at speed shown in P261 for units in
P262.
Parameter number 263
File:group Profile Test Data
Parameter type Setup
Display x
Factory default 0
Minimum value 0
Maximum value 3
Conversion
