Parameters 11-73
229
Int Torque Ref
1
Int Torque Ref shows the value of torque reference that is present
at the output of the torque limiter.
1 Int Torque Ref was added in Version 3.xx.
Parameter number 229
File:group Monitor: Motor Status
Parameter type source
Display ±x.x%
Factory default 0.0%
Minimum value -800%
Maximum value +800%
Conversion 4096 = Rated Torque
230
Iq Offset
1
IQ Offset contains the LEM U offset required to null the current
error (no motor current flowing). This offset is set automatically
by running the transistor diagnostics.
1 Iq Offset was added in Version 3.xx.
Parameter number 230
File:group None
Parameter type linkable destination
Display ±x
Factory default 0
Minimum value -100
Maximum value +100
Conversion 1 = 1
231
Id Offset
1
Id Offset contains the LEM W offset required to null the current
error (no motor current flowing). This offset is set automatically
by running the transistor diagnostics.
1 Id Offset was added in Version 3.xx.
Parameter number 231
File:group None
Parameter type linkable destination
Display ±x
Factory default 0
Minimum value -100
Maximum value +100
Conversion 1 = 1
232
Function In9
1
Use Function In9 to provide input to the function block that is
provided with the 1336 IMPACT drive.
1 Function In9 was added in Version 3.xx.
Parameter number 232
File:group Application: Prog Function
Parameter type sink
Display ±x
Factory default 0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
Refer to Chapter 10, Using the Function Block, for more
information.
233
Function In10
1
Use Function In10 to provide input to the function block that is
provided with the 1336 IMPACT drive.
1 Function In10 was added in Version 3.xx.
Parameter number 233
File:group Application: Prog Function
Parameter type sink
Display ±x
Factory default 0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
Refer to Chapter 10, Using the Function Block, for more
information.
234
Motor Voltage %
1
Use Motor Voltage % to view the actual line-to-line fundamental
RMS value of motor voltage as a percentage. This data is
averaged and updated every 50 milliseconds.
1 Motor Voltage was added in Version 3.xx.
Parameter number 234
File:group Monitor:Motor Status
Parameter type source
Display x.x%
Factory default NA
Minimum value 0%
Maximum value 800%
Conversion 4096 = motor volts
