Parameters 11-71
221
Fault Status 1
1
Fault Status 1 shows fault conditions that have been configured
to report as drive fault conditions. Each configuration bit matches
the bit definitions of Fault Select 1 (parameter 20) and Fault
Select 2 (parameter 22). When a bit is “1” the condition is true;
otherwise, the condition is false.
1 Fault Status 1 was added in Version 3.xx.
Parameter number 221
File:group Monitor: Fault Status
Parameter type source
Display Bits
Factory default 0000 0000 0000 0000
Minimum value 0000 0000 0000 0000
Maximum value 1111 1111 1111 1111
Conversion 1 = 1
Refer to Chapter 12, Troubleshooting, for more information.
Bit Condition
0 Ridethru Time
1 Prechrg Time
2 Bus Drop
3 Bus Undervlt
4 Bus Cycles>5
5 Open Circuit
Bit Condition
6 Reserved
7 Reserved
8 mA Input
9 SP 1 Timeout
10 SP 2 Timeout
11 SP 3 Timeout
Bit Condition
12 SP 4 Timeout
13 SP 5 Timeout
14 SP 6 Timeout
15 SP Error
222
Fault Status 2
1
Fault Status 2 shows fault conditions that have been configured
to report as drive fault conditions. Each configuration bit matches
the bit definitions of Fault Select 1 (parameter 20) and Fault
Select 2 (parameter 22). When a bit is “1” the condition is true;
otherwise, the condition is false.
1 Fault Status 2 was added in Version 3.xx.
Parameter number 222
File:group Monitor: Fault Status
Parameter type source
Display Bits
Factory default 0000 0000 0000 0000
Minimum value 0000 0000 0000 0000
Maximum value 1111 1111 1111 1111
Conversion 1 = 1
Refer to Chapter 12, Troubleshooting, for more information.
Bit Condition
0 SpdFdbk Loss
1 InvOvtmp Pnd
2 Reserved
3 MtrOvld Pend
4 MtrOvld Trip
5 Mtr Stall
Bit Condition
6 Ext Fault In
7 Reserved
8 Reserved
9 Param Limit
10 Math Limit
11 Reserved
Bit Condition
12 Reserved
13 InOvld Pend
14 Reserved
15 InvOvld Trip
223
Warning Status 1
1
Warning Status 1 shows warning conditions that have been
configured to report as drive warning conditions. Each
configuration bit matches the bit definitions of Warning Select 1
(parameter 21) and Warning Select 2 (parameter 23). When a bit
is “1” the condition is true; otherwise, the condition is false.
1 Warning Status 1 was added in Version 3.xx.
Parameter number 223
File:group Monitor: Fault Status
Parameter type source
Display Bits
Factory default 0000 0000 0000 0000
Minimum value 0000 0000 0000 0000
Maximum value 1111 1111 1111 1111
Conversion 1 = 1
Refer to Chapter 12, Troubleshooting, for more information.
Bit Condition
0 Ridethru Time
1 Prechrg Time
2 Bus Drop
3 Bus Undervlt
4 Bus Cycles>5
5 Open Circuit
Bit Condition
6 Reserved
7 Reserved
8 mA Input
9 SP 1 Timeout
10 SP 2 Timeout
11 SP 3 Timeout
Bit Condition
12 SP 4 Timeout
13 SP 5 Timeout
14 SP 6 Timeout
15 SP Error
