Parameters 11-69
213
Function Output 1
1
Use Function Output 1 to view the results of the function block.
Function Output 1 is either a word value or the upper byte of a
double word, depending on the value of Function Sel
(parameter 212).
1 Function Output 1 was added in Version 2.xx.
Parameter number 213
File:group Application:Prog Function
Parameter type source
Factory default not applicable
Conversion 1 = 1
If Function Sel (parameter 212) is 0 – 8, then:
Display bits
Minimum value 00000000.00000000
Maximum value 11111111.11111111
If Function Sel (parameter 212) is 9, 10, 12 or 13, then:
Display ±x
Minimum value -32767
Maximum value +32767
If Function Sel (parameter 212) is 11, then:
Display x
Minimum value 0
Maximum value 65535
Refer to Chapter 10, Using the Function Block, for more
information.
214
Function Output2
1
Use Function Output 2 to view the results of the function block.
Function Output 2 is the lower byte of a double word Function Sel
(parameter 212) is 11, 12, or 13.
1 Function Output 2 was added in Version 2.xx.
Parameter number 214
File:group Application:Prog Function
Parameter type source
Display x
Factory default not applicable
Minimum value 0
Maximum value 65535
Conversion 1 = 1
Refer to Chapter 10, Using the Function Block, for more
information.
215
Min Speed Limit
1
Use Min Speed Limit to specify the minimum speed that you want
the motor to run at. Min Speed Limit overrides any speed
references to lower speeds.
1 Min Speed Limit was added in Version 2.xx.
Parameter number 215
File:group Control:Control Limits
Parameter type linkable destination
Display x.x rpm
Factory default 0.0 rpm
Minimum value 0.0 rpm
Maximum value base motor speed
Conversion 4096 = base motor speed
216
Fstart Select
1
Use Fstart Select to activate the flying start feature when
operating in Encoderless mode. This allows encoderless mode
the ability to reconnect into a rotating motor and resume
operation.
Note: Encoder mode will automatically reconnect and does not
use the Fstart Select parameter.
1 Fstart Select was added in Version 3.xx.
Parameter number 216
File:group Application: Flying Start
Parameter type linkable destination
Display x
Factory default 0
Minimum value 0
Maximum value 2
Conversion 1 = 1
Refer to Chapter 9, Applications, for more information.
Display# Display Text Description
0 Disabled Flying start disabled
1 Last Speed Flying start enabled — Beginning search from last known speed
2 Speed Param Flying start enabled — Beginning search from Fstart Speed (parameter 217)
