11-68 Parameters
212
Function Sel
1
Use Function Sel to select which function you would like the
function block to perform.
1 Function Sel was added in Version 2.xx.
Parameter number 212
File:group Application:Prog Function
Parameter type destination
Display x
Factory default 0
Minimum value 0
Maximum value 27
Conversion 1 = 1
Refer to Chapter 10, Using the Function Block, for more
information.
Value Description
0 Or Tmr
Take the OR of input 1 and input 2
and use the result for the timer
input.
1 Nor Tmr
Take the NOR of input 1 and
input 2 and use the result for the
timer input.
2 And Tmr
Take the AND of input 1 and
input 2 and use the result for the
timer input.
3 Nand Tmr
Take the NAND of input 1 and
input 2 and use the result for the
timer input.
4 Or And Tmr
Take the result of input 1 OR’ed
with input 2 and AND with input 3.
Then,use the result for the timer
input.
5 And Or Tmr
Take the result of input 1 AND
input 2 and OR with input 3. Then,
use the result for the timer input.
6 Tmr Or And
Use input 1 for the timer input and
OR with input 2. Then, AND with
input 3.
7 Tmr And Or
Use input 1 for the timer input and
AND with input 2. Then, OR with
input 3.
8 StateMachine
Change the output value based on
the value of input 1/timer and
input 2.
9 Add/Sub
Add input 1 and input 2.
Value Description
10 Max/Min
Compare input 1 with input 2 and
based on input 3, output
whichever value is larger or
smaller.
11 Counter
Count up (input 1) or down
(input 2).
12 Mult/Div
Multiply input 1 and input 2 and
then divide by input 3.
13 Scale
Scale the value of input 1 from
one range to another.
14 Hysteresis
Create Hysteresis band (In4-Hi,
In5-Lo) for Input 1.
15 Band
Create Band (In4-Hi, In5-Lo) for
Input 1.
16 Or Add
Take the OR of input 1 and input 2
and use the result for the add/sub
input.
17 Nor Add
Take the NOR of input 1 and
input 2 and use the result for the
add/sub input.
18 And Add
Take the AND of input 1 and
input 2 and use the result for the
add/sub input.
19 Nand Add
Take the NAND of input 1 and
input 2 and use the result for the
add/sub input.
Value Description
20 Or And Add
Take the result of input 1 OR’ed
with input 2 and AND with input 3.
Then, use the result for the
add/sub input.
21 And Or Add
Take the result of input 1 AND
input 2 and OR with input 3. Then,
use the result for the add/sub
input.
22 Or Mult
Take the OR of input 1 and input 2
and use the result for the mult/div
input.
23 Nor Mult
Take the NOR of input 1 and
input 2 and use the result for the
mult/div input.
24 And Mult
Take the AND of input 1 and
input 2 and use the result for the
mult/div input.
25 Nand Mult
Take the NAND of input 1 and
input 2 and use the result for the
mult/div input.
26 Or And Mult
Take the result of input 1 OR’ed
with input 2 and AND with input 3.
Then, use the result for the
mult/div input.
27 And Or Mult
Take the result of input 1 AND
input 2 and OR with input 3. Then,
use the result for the mult/div
input.
