Function In1
1
Use Function In1 to provide input into the function block that is
provided with the 1336 IMPACT drive. You can choose to either
evaluate the input value or pass the value directly to the function
block.
To evaluate Function In1, you need to also use Func 1 Mask/Val
(parameter 199) and Func 1 Eval Sel (parameter 200).
To pass the value directly to the function block, enter a value of 0
into Func 1 Eval Sel.
1 Function In1 was added in Version 2.xx.
Parameter number 198
File:group Application:Prog Function
Parameter type linkable destination
Conversion 1 = 1
If Func 1 Eval Sel (parameter 200) is 0 or 6 – 11, then:
Display ±x
Factory default 0
Minimum value -32767
Maximum value +32767
If Func 1 Eval Sel (parameter 200) is 1 – 5, then:
Display bits
Factory default 00000000.00000000
Minimum value 00000000.00000000
Maximum value 11111111.11111111
If Func 1 Eval Sel (parameter 200) is 12 – 15, then:
Display x
Factory default 0
Minimum value 0
Maximum value 65535
Refer to Chapter 10, Using the Function Block, for more
information.
199
Func 1 Mask/Val
1
Use Func 1 Mask/Val to enter a mask or value to compare
Function In1 (parameter 198) to, according to the value you
select in Func 1 Eval Sel (parameter 200).
1 Func 1 Mask/Val was added in Version 2.xx.
Parameter number 199
File:group Application:Prog Function
Parameter type linkable destination
Conversion 1 = 1
If Func 1 Eval Sel (parameter 200) is 0 or 6 – 11, then:
Display ±x
Factory default -1
Minimum value -32767
Maximum value +32767
If Func 1 Eval Sel (parameter 200) is 1 – 5, then:
Display bits
Factory default 11111111.11111111
Minimum value 00000000.00000000
Maximum value 11111111.11111111
If Func 1 Eval Sel (parameter 200) is 12 – 15, then:
Display x
Factory default 65535
Minimum value 0
Maximum value 65535
Refer to Chapter 10, Using the Function Block, for more
information.
