User Manual V 1-4.XX User guide

11-60 Parameters
196
Drive/Inv Sts 2
1
Use Drive/Inv Sts 2 to view the status/conditions within the drive.
When a bit is set (1), the corresponding condition in the drive is
true.
1 Drive/Inv Sts 2 was added in Version 2.xx.
When set, the bits are defined as the following:
Parameter number 196
File:group Monitor:Drive/Inv Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Bit Description
0 Flux Ready
The motor is ready to be fluxed
up.
1 Flux Up
The motor is fluxed up.
2 DC Braking
DC braking is currently being
used.
3 Reserved
Leave 0.
4 Bus Ridethru
The drive is in a bus ridethrough
condition.
5 Jogging
The drive is jogging.
Bit Description
6 Searching
Flying start is syncing with motor.
7 Enc TrimLoss
Indicates encoder loss when
using Encoder switchover mode
8 At Limit
The motor is at the At Limit set
point.
9 Func Output
Function Output 1
(parameter 213) and/or Function
Output 2 (parameter 214) is non-
zero.
10 – 11 Reserved
Leave 0.
Bit Description
12 Relay Setpt1
Relay 1 has reached Relay
Setpoint 1 (parameter 115).
13 Relay Setpt2
Relay 2 has reached Relay
Setpoint 2 (parameter 188).
14 Relay Setpt3
Relay 3 has reached Relay
Setpoint 3 (parameter 190).
15 Relay Setpt4
Relay 4 has reached Relay
Setpoint 4 (parameter 192).
197
Logic Cmd Input
1
Use Logic Cmd Input to change the logic evaluation block. The
bits that you change here are reflected in Logic Input Sts
(parameter 14).
1 Logic Cmd Input was added in Version 2.xx.
The bits are defined as follows:
Parameter number 197
File:group none
Parameter type linkable destination
Display bits
Factory default 00000000.00000000
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Bit Description
0 Normal Stop
A ramp stop is selected.
1 Start
A start is in progress.
2 Jog 1
A jog 1 is in progress.
3 Clear Fault
A clear fault is in progress.
4 Forward
A forward was commanded.
Bit Description
5 Reverse
A reverse was commanded.
6 Jog 2
A jog 2 is in progress.
7 Cur Lim Stop
A current limit stop is
selected.
8 Coast Stop
A coast stop is selected.
9 Spd Ramp Dis
Ramps are disabled.
Bit Description
10 Flux Enable
Flux is enabled.
11 Process Trim
Process trim is enabled.
12 Speed Ref A
13 Speed Ref B
14 Speed Ref C
15 Reset Drive
The drive has been
commanded to reset.
CBA
0 0 0 No Charge
0 0 1 Speed Ref 1
0 1 0 Speed Ref 2
0 1 1 Speed Ref 3
1 0 0 Speed Ref 4
1 0 1 Speed Ref 5
1 1 0 Speed Ref 6
1 1 1 Speed Ref 7
