Parameters 11-59
193
Start Dwell Spd
1
Start Dwell Spd lets you set the speed that the drive immediately
outputs when a start command is issued. No acceleration ramp
is used. You must enter a time value in Start Dwell Time
(parameter 194).
1 Start Dwell Spd was added in Version 2.xx.
Parameter number 193
File:group Control:Drive Logic Sel
Parameter type linkable destination
Display ±x.x rpm
Factory default +0.0 rpm
Minimum value -0.1 x base motor speed
Maximum value +0.1 x base motor speed
Conversion 4096 = base motor speed
Refer to the Speed Reference Selection Overview section in
Appendix B, Control Block Diagrams, for more information.
194
Start Dwell Time
1
Start Dwell Time lets you specify how long you want the drive to
continue using Start Dwell Spd (parameter 193) before ramping
to whichever speed reference you have selected (speed
references 1 through 7).
1 Start Dwell Time was added in Version 2.xx.
Parameter number 194
File:group Control:Drive Logic Sel
Parameter type linkable destination
Display x.x seconds
Factory default 0.0 seconds
Minimum value 0.0 seconds
Maximum value 10.0 seconds
Conversion seconds x 10
Refer to the Speed Reference Selection Overview section in
Appendix B, Control Block Diagrams, for more information.
195
Max Mtr Current
1
Use Max Mtr Current to increase the maximum motor current
from 200% to 400% if you are using a drive that is significantly
larger than your motor.
Regardless of your selection, the drive limits current to 150% of
the rated inverter current.
1 Max Mtr Current was added in Version 2.xx.
Parameter number 195
File:group Control:Control Limits
Application:200/400% Mtr Cur
Parameter type destination
Display x
Factory default 0
Minimum value 0
Maximum value 1
Conversion 1 = 1
Refer to the Using Up to 400% Motor Current section of
Chapter 9, Applications.
Choose: To Select:
0 200% maximum motor current
1 400% maximum motor current
