11-54 Parameters
180 Freq Track Filtr
Freq Track Filtr contains the rotor frequency regulator filter in
encoderless mode. Do not change the value of this parameter.
Parameter number 180
File:group none
Parameter type destination
Display x
Factory default 5000
Minimum value 0
Maximum value 32767
Conversion 1 = 1
181
SP 2 Wire Enable
1
SP 2 Wire Enable lets you specify whether the specified
SCANport device uses 2 wire or 3 wire control. When you are
operating in 2 wire control, the start button acts like a jog.
1 SP 2 Wire Enable was added in Version 2.xx.
Parameter number 181
File:group Interface/Comm:SCANport Config
Parameter type destination
Display bits
Factory default 00000000
Minimum value 00000000
Maximum value 11111110
Conversion 1 = 1
Bit Description
0 Reserved
Leave 0.
1 SP 1
Set to enable the device connected to SCANport 1 for
2 wire control.
2 SP 2
Set to enable the device connected to SCANport 2 for
2 wire control.
3 SP 3
Set to enable the device connected to SCANport 3 for
2 wire control.
Bit Description
4 SP 4
Set to enable the device connected to SCANport 4 for
2 wire control.
5 SP 5
Set to enable the device connected to SCANport 5 for
2 wire control.
6 SP 6
Set to enable the device connected to SCANport 6 for
2 wire control.
7 P197
Set to enable Logic Cmd Input (parameter 197) for 2
wire control.
182
An In1 Filter BW
1
Use An In1 Filter BW to use a low pass filter on the analog
input 1. This filter adjusts the bandwidth to get better filtering. By
using the low pass filter, you lose some bandwidth, but the value
becomes more stable.
1 An In1 Filter BW was added in Version 2.xx.
Parameter number 182
File:group Interface/Comm:Analog Inputs
Parameter type linkable destination
Display x.x radians per second
Factory default 0.0 radians per second
Minimum value 0.0 radians per second
Maximum value 200.0 radians per second
Conversion 10 = 1
183
An In2 Filter BW
1
Use An In2 Filter BW to use a low pass filter on the analog
input 2. This filter adjusts the bandwidth to get better filtering. By
using the low pass filter, you lose some bandwidth, but the value
becomes more stable.
1 An In1 Filter BW was added in Version 2.xx.
Parameter number 183
File:group Interface/Comm:Analog Inputs
Parameter type linkable destination
Display x.x radians per second
Factory default 0.0 radians per second
Minimum value 0.0 radians per second
Maximum value 200.0 radians per second
Conversion 10 = 1
184
mA In Filter BW
1
Use mA In Filter BW to use a low pass filter on the 4 – 20 mA
input. This filter adjusts the bandwidth to get better filtering. By
using the low pass filter, you lose some bandwidth, but the value
becomes more stable.
1 mA In Filter BW was added in Version 2.xx.
Parameter number 184
File:group Interface/Comm:Analog Inputs
Parameter type linkable destination
Display x.x radians per second
Factory default 0.0 radians per second
Minimum value 0.0 radians per second
Maximum value 200.0 radians per second
Conversion 10 = 1
