Parameters 11-53
176 Autotune Errors
Autotune Errors shows the results of the auto-tune tests. The test
results are divided into four categories: slip calculations, leakage
inductance tests, resistance tests, and flux current tests. If a fault
occurred during the auto-tune tests, the appropriate bit is set in
Autotune Errors. If no bits are set, the drive passed all of the
auto-tune tests.
The bits are defined as follows:
Parameter number 176
File:group Autotune:Autotune Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Refer to Chapter 13, Understanding the Auto-tuning Procedure,
for more information.
Bit Description Bit Description Bit Description
0
Slip <= 0 Resistance Tests Flux Current Tests
Slip is 0 or negative. 6 Res- > 0 Spd 11 Flx-Atune Lo
Inductance Tests Not at zero speed. Auto-tune setpoint is too low.
1 Ind- > 0 Spd 7 Res-Sign Err 12 Flx-Flux < 0
Not at zero speed. Sign error. Flux less than zero.
2 Ind-Sign Err 8 Res- 0 Cur 13 Flx-Cur>MCur
Sign error or negative Lsigma. Zero current. Flux current > rated motor current.
3 Ind- 0 Cur 9 Res-SW Err 14 Flx-En Drop
Zero current. Software error. Enable dropout.
4 Ind-A/D Ovfl 10 Res-En Drop 15 Flx-Hi Load
A/D overflow at minimum gain. Enable dropout. The load is too high.
5 Ind-En Drop
Enable dropout.
177 Ki Freq Reg
Ki Freq Reg contains the integral gain of the frequency regulator
in encoderless mode. Do not change the value of this parameter.
Parameter number 177
File:group none
Parameter type destination
Display x
Factory default 300
Minimum value 0
Maximum value 32767
Conversion 1 = 1
178 Kp Freq Reg
Kp Freq Reg contains the proportional gain of the frequency
regulator in encoderless mode. Do not change the value of this
parameter.
Parameter number 178
File:group none
Parameter type destination
Display x
Factory default 800
Minimum value 0
Maximum value 32767
Conversion 1 = 1
179 Kf Freq Reg
Kf Freq Reg contains the feed-forward gain of the frequency
regulator in encoderless mode. Do not change the value of this
parameter.
Parameter number 179
File:group none
Parameter type destination
Display x.x
Factory default 1.0
Minimum value 0.0
Maximum value 128.0
Conversion 256 = 1.0
