Mounting and Wiring Your 1336 IMPACT Drive 2-7
NA = Not Available, use fuses
1
Bulletin 140 - At 480 volts, circuit breaker must have a fuse backup. Refer to the
AB Industrial Control Catalog. At 600 volts, additional restrictions apply. No
limitations in source short circuit ratings.
2
HMCP Circuit Breaker - HMCP Breaker is a magnetic trip device only. Always set
the trip setting as low as possible in a particular application.
3
Current limiting option can extend this value to 200,000A RMS
1336E-B350 298 (400) NA NA NA - -
1336E-BP350 261 (350) NA NA HMCP600L6W E 65,000
1336E-B400 336 (450) NA NA NA - -
1336E-BP400 298 (400) NA NA HMCP600L6W E 65,000
1336E-B450 373 (500) NA NA NA - -
1336E-BP450 336 (450) NA NA HMCP600L6W E 65,000
1336E-B500 448 (600) NA NA NA - -
1336E-C001 0.75 (1) 140-MN-0400 100,000 HMCPS003A0 E 65,000
1336E-C003 2.2 (3) 140-MN-0630 100,000 HMCPS007C0 E 65,000
1336E-C007 5.5 (7.5) 140-MN-1000 16,000 HMCPS015E0C E 65,000
1336E-C010 7.5 (10) 140-MN-1600 6,000 HMCPS015E0C E 65,000
1336E-C015 11 (15) 140-MN-2000 6,000 HMCPS030H1C F 65,000
1336E-C020 15 (20) 140-MN-2500 6,000 HMCPS030H1C H 65,000
1336E-C025 18.5 (25) 140-CMN-4000 65,000 HMCPS050K2C E 65,000
1336E-C030 22 (30) 140-CMN-4000 65,000 HMCPS050K2C G 65,000
1336E-C040 30 (40) 140-CMN-6300 50,000 HMCPS050K2C G 65,000
1336E-C050 37 (50) 140-CMN-6300 50,000 HMCPS100R3C E 65,000
1336E-C060 45 (60) 140-CMN-6300 50,000 HMCPS100R3C E 65,000
1336E-C075 56 (75) 140-CMN-9000 25,000 HMCPS100R3C G 65,000
1336E-C100 75 (100) KTA3-160S-125 65,000 HMCP150T4C E 65,000
1336E-C125 93 (125) KTA3-160S-160 65,000 HMCP150T4C E 65,000
1336E-C150 112 (150) KTA3-400S-160 65,000 HMCP150T4C G 65,000
1336E-C200 149 (200) KTA-400S-320 65,000 HMCP250J5 I 65,000
1336E-C250 187 (250) KTA3-400S-320 65,000 HMCP400W5 G 65,000
1336E-CX300 224 (300) KTA3-400S-320 65,000 HMCP400W5 H 65,000
1336E-C300 224 (300) KTA3-400S-320 65,000 HMCP400W5 H 65,000
1336E-C350 261 (350) KTA3-400S-320 65,000 NA NA NA
1336E-C400 298 (400) KTA3-400S-320 65,000 NA NA NA
1336E-C450 336 (450) NA NA NA NA NA
1336E-C500 373 (500) NA NA NA NA NA
1336E-C600 448 (600) NA NA NA NA NA
Drive
Catalog Number
Maximum
Rated Vt
kW (HP)
IEC Installations per IEC947-2 UL/CSA Installations
Bulletin 140 Circuit Breaker
HMCP Circuit Breaker
2
Catalog Number
Rated Service Short
Circuit Capability
400/415V
Catalog Number
MCP Trip
Setting
Max. Short
Circuit Amps
3
480V
