Parameters 11-47
150 Data Out B1
Use Data Out B1 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 150
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
151 Data Out B2
Use Data Out B2 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 151
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
152 Data Out C1
Use Data Out C1 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 152
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
153 Data Out C2
Use Data Out C2 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 153
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
154 Data Out D1
Use Data Out D1 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 154
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
155 Data Out D2
Use Data Out D2 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 155
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
