11-46 Parameters
144 Data In C1
Use Data In C1 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 144
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
145 Data In C2
Use Data In C2 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 145
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
146 Data In D1
Use Data In D1 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 146
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
147 Data In D2
Use Data In D2 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 147
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
148 Data Out A1
Use Data Out A1 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 148
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
149 Data Out A2
Use Data Out A2 to view the drive to SCANport image that is
sent to some device on SCANport. This image may be referred to
as the SCANport I/O image or a datalink in the manual for your
communications module.
Parameter number 149
File:group Interface/Comm:Gateway Data Out
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
