Parameters 11-45
138 SP An In2 Scale
Use SP An In2 Scale to scale SP An In2 Value (parameter 137).
Parameter number 138
File:group Interface/Comm:SCANport Analog
Parameter type linkable destination
Display ±x.xxx
Factory default +0.125
Minimum value -1.000
Maximum value +1.000
Conversion 32767 = 1.000
139 SP An Output
Use SP An Output to view the analog value that is sent to all
SCANport devices.
Note: If a link is made or changed, you may have to power cycle
the SCANport terminals to display the correct information.
Parameter number 139
File:group Interface/Comm:SCANport Analog
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
140 Data In A1
Use Data In A1 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 140
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
141 Data In A2
Use Data In A2 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 141
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
142 Data In B1
Use Data In B1 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 142
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
143 Data In B2
Use Data In B2 to view the SCANport to drive image that is
received from some device on SCANport. This image may be
referred to as the SCANport I/O image or a datalink in the
manual for your communications module.
Parameter number 143
File:group Interface/Comm:Gateway Data In
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
