11-44 Parameters
133 SP An In1 Select
Use SP An In1 Select to select which SCANport analog device is
used in SP An In1 Value (parameter 134).
Parameter number 133
File:group Interface/Comm:SCANport Analog
Parameter type linkable destination
Display x
Factory default 1
Minimum value 1
Maximum value 6
Conversion 1 = 1
Value Description
1 SP 1
Use SCANport device 1.
2 SP 2
Use SCANport device 2.
Value Description
3 SP 3
Use SCANport device 3.
4 SP 4
Use SCANport device 4.
Value Description
5 SP 5
Use SCANport device 5.
6 SP 6
Use SCANport device 6.
134 SP An In1 Value
Use SP An In1 Value to view the analog value of the SCANport
device selected in SP An In1 Select (parameter 133). You need
to link SP An In1 Value to a parameter such as Speed Ref 1
(parameter 29).
Parameter number 134
File:group Interface/Comm:SCANport Analog
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
135 SP An In1 Scale
Use SP An In1 Scale to scale SP An In1 Value (parameter 134).
Parameter number 135
File:group Interface/Comm:SCANport Analog
Parameter type linkable destination
Display ±x.xxx
Factory default +0.125
Minimum value -1.000
Maximum value +1.000
Conversion 32767 = 1.000
136 SP An In2 Select
Use SP An In2 Select to select which SCANport analog device is
used in SP An In2 Value (parameter 137).
Parameter number 136
File:group Interface/Comm:SCANport Analog
Parameter type linkable destination
Display x
Factory default 6
Minimum value 1
Maximum value 6
Conversion 1 = 1
Value Description
1 SP 1
Use SCANport device 1.
2 SP 2
Use SCANport device 2.
Value Description
3 SP 3
Use SCANport device 3.
4 SP 4
Use SCANport device 4.
Value Description
5 SP 5
Use SCANport device 5.
6 SP 6
Use SCANport device 6.
137 SP An In2 Value
Use SP An In2 Value to view the analog value of the SCANport
device selected in SP An In2 Select (parameter 136). You need
to link SP An In2 Value to a parameter such as Speed Ref 1
(parameter 29).
Parameter number 137
File:group Interface/Comm:SCANport Analog
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
