Parameters 11-43
131 Ramp/ClFlt Owner
You can use the lower byte of Ramp/ClFlt Owner (bits 0 through
7) to see which SCANport device(s) are presently issuing a valid
Clear Fault command. You can use the higher byte (bits 8
through 15) to see which SCANport device(s) are presently
issuing a valid ramp command. You can choose between:
0 = Ramp/clear fault input not present
1 = Ramp/clear fault input present
The bits are defined as follows:
Parameter number 131
File:group Monitor Status:SCANport Status
Interface/Comm:SCANport Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit Description
0 ClrFlt L Opt
The L Option board owns the
Clear Fault.
1 ClrFlt SP 1
SCANport device 1 owns the
Clear Fault.
2 ClrFlt SP 2
SCANport device 2 owns the
Clear Fault.
3 ClrFlt SP 3
SCANport device 3 owns the
Clear Fault.
4 ClrFlt SP 4
SCANport device 4 owns the
Clear Fault.
Bit Description
5 ClrFlt SP 5
SCANport device 5 owns the
Clear Fault.
6 ClrFlt SP 6
SCANport device 6 owns the
Clear Fault.
7 ClrFlt P197
Logic Cmd Input (parameter 197)
owns the Clear Fault.
8 Ramp L Opt
The L Option owns the Ramp.
9 Ramp SP 1
SCANport device 1 owns the
Ramp.
10 Ramp SP 2
SCANport device 2 owns the
Ramp.
Bit Description
11 Ramp SP 3
SCANport device 3 owns the
Ramp.
12 Ramp SP 4
SCANport device 4 owns the
Ramp.
13 Ramp SP 5
SCANport device 5 owns the
Ramp.
14 Ramp SP 6
SCANport device 6 owns the
Ramp.
15 Ramp P197
Logic Cmd Input (parameter 197)
owns the Ramp.
132 Flux/Trim Owner
You can use the lower byte of Flux/Trim Owner (bits 0 through 7)
to see which SCANport device(s) are currently issuing a valid
process trim command. You can use the higher byte (bits 8
through 15) to see which SCANport device(s) are presently
issuing a valid flux command. You can choose between:
0 = Flux/trim input not present
1 = Flux/trim input present
The bits are defined as follows:
Parameter number 132
File:group Monitor Status:SCANport Status
Interface/Comm:SCANport Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit Description
0 Trim L Opt
The L Option board owns the
Trim.
1 Trim SP 1
SCANport device 1 owns the
Trim.
2 Trim SP 2
SCANport device 2 owns the
Trim.
3 Trim SP 3
SCANport device 3 owns the
Trim.
4 Trim SP 4
SCANport device 4 owns the
Trim.
5 Trim SP 5
SCANport device 5 owns the
Trim.
Bit Description
6 Trim SP 6
SCANport device 6 owns the
Trim.
7 Trim P197
Logic Cmd Input (parameter 197)
owns the Trim.
8 Flux L Opt
The L Option owns the Flux.
9 Flux SP 1
SCANport device 1 owns the
Flux.
10 Flux SP 2
SCANport device 2 owns the
Flux.
Bit Description
11 Flux SP 3
SCANport device 3 owns the
Flux.
12 Flux SP 4
SCANport device 4 owns the
Flux.
13 Flux SP 5
SCANport device 5 owns the
Flux.
14 Flux SP 6
SCANport device 6 owns the
Flux.
15 Flux P197
Logic Cmd Input (parameter 197)
owns the Flux.
