11-42 Parameters
129 Start/Stop Owner
You can use the lower byte of Start/Stop Owner (bits 0 through 7)
to see which SCANport device(s) are presently issuing a valid
stop command. You can use the higher byte (bits 8 through 15) to
see which SCANport device(s) are presently issuing a valid start
command. You can choose between:
0 = Stop/start input not present
1 = Stop/start input present
The bits are defined as follows:
Parameter number 129
File:group Monitor Status:SCANport Status
Interface/Comm:SCANport Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit Description
0 Stop L Opt
The L Option board owns the
stop.
1 Stop SP 1
SCANport device 1 owns the
stop.
2 Stop SP 2
SCANport device 2 owns the
stop.
3 Stop SP 3
SCANport device 3 owns the
stop.
4 Stop SP 4
SCANport device 4 owns the
stop.
5 Stop SP 5
SCANport device 5 owns the
stop.
Bit Description
6 Stop SP 6
SCANport device 6 owns the
stop.
7 Stop P197
Logic Cmd Input (parameter 197)
owns the stop.
8 Start L Opt
The L Option owns the start.
9 Start SP 1
SCANport device 1 owns the
start.
10 Start SP 2
SCANport device 2 owns the
start.
Bit Description
11 Start SP 3
SCANport device 3 owns the
start.
12 Start SP 4
SCANport device 4 owns the
start.
13 Start SP 5
SCANport device 5 owns the
start.
14 Start SP 6
SCANport device 6 owns the
start.
15 Start P197
Logic Cmd Input (parameter 197)
owns the start.
130 Jog1/Jog2 Owner
You can use the lower byte of Jog1/Jog2 Owner (bits 0 through 7)
to see which SCANport device(s) are presently issuing a valid
jog 2 command. You can use the higher byte (bits 8 through 15)
to see which SCANport device(s) are presently issuing a valid
jog 1 command. You can choose between:
0 = Jog 1/jog 2 input not present
1 = Jog 1/jog 2 input present
The bits are defined as follows:
Parameter number 130
File:group Monitor Status:SCANport Status
Interface/Comm:SCANport Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit Description
0 Jog2 L Opt
The L Option board owns the
Jog2.
1 Jog2 SP 1
SCANport device 1 owns the
Jog2.
2 Jog2 SP 2
SCANport device 2 owns the
Jog2.
3 Jog2 SP 3
SCANport device 3 owns the
Jog2.
4 Jog2 SP 4
SCANport device 4 owns the
Jog2.
5 Jog2 SP 5
SCANport device 5 owns the
Jog2.
Bit Description
6 Jog2 SP 6
SCANport device 6 owns the
Jog2.
7 Jog2 P197
Logic Cmd Input (parameter 197)
owns the Jog2.
8 Jog1 L Opt
The L Option owns the Jog1.
9 Jog1 SP 1
SCANport device 1 owns the
Jog1.
10 Jog1 SP 2
SCANport device 2 owns the
Jog1.
Bit Description
11 Jog1 SP 3
SCANport device 3 owns the
Jog1.
12 Jog1 SP 4
SCANport device 4 owns the
Jog1.
13 Jog1 SP 5
SCANport device 5 owns the
Jog1.
14 Jog1 SP 6
SCANport device 6 owns the
Jog1.
15 Jog1 P197
Logic Cmd Input (parameter 197)
owns the Jog1.
