2-6 Mounting and Wiring Your 1336 IMPACT Drive
1336E-AQF50 3.7 (5) 140-MN-2500 6,000 HMCPS03H1C H 65,000
1336E-A007 5.5 (7.5) 140-CMN-4000 65,000 HMCPS030H1C H 65,000
1336E-A010 7.5 (10) 140-CMN-4000 65,000 HMCPS050K2C F 65,000
1336E-A015 11 (15) 140-CMN-6300 50,000 HMCPS050K2C H 65,000
1336E-A020 15 (20) 140-CMN-6300 50,000 HMCPS100R3C G 65,000
1336E-A025 18.5 (25) 140-CMN-9000 25,000 HMCPS100R3C H 65,000
1336E-A030 22 (30) 140-CMN-9000 25,000 HMCPS100R3C H 65,000
1336E-A040 30 (40) KTA3-160S-125 65,000 HMCP150T4C F 65,000
1336E-A050 37 (50) KTA3-160S-160 65,000 HMCP150T4C G 65,000
1336E-A060 45 (60) KTA3-250S-200 65,000 HMCP250A5 E 65,000
1336E-A075 56 (75) KTA3-250S-250 65,000 HMCP250A5 E 65,000
1336E-A100 75 (100) KTA3-400S-320 65,000 HMCP400J5 I 65,000
1336E-A125 93 (125) KTA3-400S-320 65,000 HMCP400J5 I 65,000
1336E-BRF05 0.37 (0.5) 140-MN-0250 100,000 HMCPS003A0 E 65,000
1336E-BRF07 0.56 (0.75) 140-MN-0250 100,000 HMCPS003A0 G 65,000
1336E-BRF10 0.75 (1) 140-MN-0400 100,000 HMCPS003A0 G 65,000
1336E-BRF15 1.2 (1.5) 140-MN-0400 100,000 HMCPS007C0 B 65,000
1336E-BRF20 1.5 (2) 140-MN-0630 100,000 HMCPS007C0 C 65,000
1336E-BRF30 2.2 (3) 140-MN-1000 16,000 HMCPS015E0C B 65,000
1336E-BRF50 3.7 (5) 140-MN-1000 16,000 HMCPS015E0C D 65,000
1336E-BRF75 5.5 (7.5) 140-MN-1600 6,000 HMCPS015E0C H 65,000
1336E-BRF100 7.5 (10) 140-MN-2000 6,000 HMCPS030H1C H 65,000
1336-B010 11 (15) 140-MN-2000 6,000 HMCPS030H1C E 65,000
1336-B015 15 (20) 140-MN-2500 6,000 HMCPS030H1C H 65,000
1336-B020 18.5 (25) 140-CMN-4000 65,000 HMCPS050K2C H 65,000
1336-B025 22 (30) 140-CMN-4000 65,000 HMCPS050K2C H 65,000
1336-B030 22 (30) 140-CMN-6300 50,000 HMCPS050K2C H 65,000
1336-BX040 30 (40) 140-CMN-6300 50,000 HMCPS050K2C H 65,000
1336-B040 37 (50) 140-CMN-6300 50,000 HMCPS100R3C G 65,000
1336-B050 45 (60) 140-CMN-9000 25,000 HMCPS100R3C G 65,000
1336E-BX060 45 (60) 140-CMN-9000 25,000 HMCPS100R3C G 65,000
1336E-B060 56 (75) KTA3-160S-125 65,000 HMCPS150T4C F 65,000
1336E-B075 75 (100) KTA3-160S-125 65,000 HMCPS150T4C H 65,000
1336E-B100 93 (125) KTA3-160S-160 65,000 HMCPS150U4C E 65,000
1336E-B125 112 (150) KTA3-250S-200 65,000 HMCP250K5 H 65,000
1336E-BX150 112 (150) KTA3-250S-200 65,000 HMCP250K5 H 65,000
1336E-B150 149 (200) KTA3-400S-320 65,000 HMCP250L5 I 65,000
1336E-B200 187 (250) KTA3-400S-320 65,000 HMCP400N5 H 65,000
1336E-B250 224 (300) KTA3-400S-400 65,000 HMCP400N5 I 65,000
1336E-BP250 224 (300) KTA3-400S-400 65,000 HMCP400N5 I 65,000
1336E-B300 261 (350) NA - NA - -
1336E-BP300 298 (400) KTA-400S-400 65,000 HMCP400R5 I 65,000
Drive
Catalog Number
Maximum
Rated Vt
kW (HP)
IEC Installations per IEC947-2 UL/CSA Installations
Bulletin 140 Circuit Breaker
HMCP Circuit Breaker
2
Catalog Number
Rated Service Short
Circuit Capability
400/415V
Catalog Number
MCP Trip
Setting
Max. Short
Circuit Amps
3
480V
