Parameters 11-41

127 Clr Flt/Res Mask

You can use the lower byte of Clr Flt/Res Mask (bits 0 through 7)

to select which SCANport devices can issue a Reset Drive

command. You can use the higher byte (bits 8 through 15) to

select which SCANport devices can issue a Clear Faults

command. You can choose between:

0 = Disable control

1 = Enable control

The bits are deﬁned as follows:

Parameter number 127

File:group Interface/Comm:SCANport Conﬁg

Parameter type linkable destination

Display bits

Factory default 11111111.11111111

Minimum value 00000000.00000000

Maximum value 11111111.11111111

Conversion 1 = 1

Refer to Chapter 8, Using the SCANport Capabilities, for more

information.

Bit Description

0 Reset L Opt

Let the L Option board control

resets.

1 Reset SP 1

Let SCANport device 1 control

resets.

2 Reset SP 2

Let SCANport device 2 control

resets.

3 Reset SP 3

Let SCANport device 3 control

resets.

4 Reset SP 4

Let SCANport device 4 control

resets.

5 Reset SP 5

Let SCANport device 5 control

resets.

Bit Description

6 Reset SP 6

Let SCANport device 6 control

resets.

7 Reset P197

Let Logic Cmd Input

(parameter 197) control resets.

8 ClrFlt L Opt

Let the L Option board control

clear fault commands.

9 ClrFlt SP 1

Let SCANport device 1 control

clear fault commands.

10 ClrFlt SP 2

Let SCANport device 2 control

clear fault commands.

11 ClrFlt SP 3

Let SCANport device 3 control

clear fault commands.

Bit Description

12 ClrFlt SP 4

Let SCANport device 4 control

clear fault commands.

13 ClrFlt SP 5

Let SCANport device 5 control

clear fault commands.

14 ClrFlt SP 6

Let SCANport device 6 control

clear fault commands.

15 ClrFlt P197

Let Logic Cmd Input

(parameter 197) control clear

fault commands.

128 Dir/Ref Owner

You can use the lower byte of Dir/Ref Owner (bits 0 through 7) to

see which SCANport device currently has exclusive control of the

reference changes. You can use the higher byte (bits 8 through

15) to see which SCANport device currently has exclusive control

of direction changes. You can choose between:

0 = Reference/direction input not present

1 = Reference/direction input present

The bits are deﬁned as follows:

Parameter number 128

File:group Monitor Status:SCANport Status

Interface/Comm:SCANport Status

Parameter type source

Display bits

Factory default not applicable

Minimum value 00000000.00000000

Maximum value 11111111.11111111

Conversion 1 = 1

Refer to Chapter 8, Using the SCANport Capabilities, for more

information.

Bit Description

0 Refer L Opt

The L Option board owns the

reference command.

1 Refer SP 1

SCANport device 1 owns the

reference command.

2 Refer SP 2

SCANport device 2 owns the

reference command.

3 Refer SP 3

SCANport device 3 owns the

reference command.

4 Refer SP 4

SCANport device 4 owns the

reference command.

5 Refer SP 5

SCANport device 5 owns the

reference command.

Bit Description

6 Refer SP 6

SCANport device 6 owns the

reference command.

7 Refer P197

Logic Cmd Input (parameter 197)

owns the reference command.

8 Direct L Opt

The L Option board owns the

direct command.

9 Direct SP 1

SCANport device 1 owns the

direct command.

10 Direct SP 2

SCANport device 2 owns the

direct command.

Bit Description

11 Direct SP 3

SCANport device 3 owns the

direct command.

12 Direct SP 4

SCANport device 4 owns the

direct command.

13 Direct SP 5

SCANport device 5 owns the

direct command.

14 Direct SP 6

SCANport device 6 owns the

direct command.

15 Direct P197

Logic Cmd Input (parameter 197)

owns the direct command.
