125 Dir/Ref Mask
You can use the lower byte of Dir/Ref Mask (bits 0 through 7) to
select which SCANport device can issue a reference command.
You can use the higher byte (bits 8 through 15) to select which
SCANport devices can issue a forward/reverse direction
command. You can choose between:
0 = Disable control
1 = Enable control
The bits are defined as follows:
Parameter number 125
File:group Interface/Comm:SCANport Config
Parameter type linkable destination
Display bits
Factory default 11111111.11111111
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit Description
0 Refer L Opt
Let the L Option board control the
reference.
1 Refer SP 1
Let SCANport device 1 control
the reference.
2 Refer SP 2
Let SCANport device 2 control
the reference.
3 Refer SP 3
Let SCANport device 3 control
the reference.
4 Refer SP 4
Let SCANport device 4 control
the reference.
5 Refer SP 5
Let SCANport device 5 control
the reference.
Bit Description
6 Refer SP 6
Let SCANport device 6 control
the reference.
7 Refer P197
Let Logic Cmd Input
(parameter 197) control the
reference.
8 Direct L Opt
Let the L Option board control the
direction.
9 Direct SP 1
Let SCANport device 1 control
the direction.
10 Direct SP 2
Let SCANport device 2 control
the direction.
11 Direct SP 3
Let SCANport device 3 control
the direction.
Bit Description
12 Direct SP 4
Let SCANport device 4 control
the direction.
13 Direct SP 5
Let SCANport device 5 control
the direction.
14 Direct SP 6
Let SCANport device 6 control
the direction.
15 Direct P197
Let Logic Cmd Input
(parameter 197) control the
direction.
126 Start/Jog Mask
You can use the lower byte of Start/Jog Mask (bits 0 through 7) to
select which SCANport devices can issue a jog reference
command. You can use the higher byte (bits 8 through 15) to
select which SCANport devices can issue a start command. You
can choose between:
0 = Disable control
1 = Enable control
The bits are defined as follows:
Parameter number 126
File:group Interface/Comm:SCANport Config
Parameter type linkable destination
Display bits
Factory default 11111111.11111111
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit Description
0 Jog L Opt
Let the L Option board control
jogs.
1 Jog SP 1
Let SCANport device 1 control
jogs.
2 Jog SP 2
Let SCANport device 2 control
jogs.
3 Jog SP 3
Let SCANport device 3 control
jogs.
4 Jog SP 4
Let SCANport device 4 control
jogs.
5 Jog SP 5
Let SCANport device 5 control
jogs.
Bit Description
6 Jog SP 6
Let SCANport device 6 control
jogs.
7 Jog P197
Let Logic Cmd Input
(parameter 197) control jogs.
8 Start L Opt
Let the L Option board control
starts.
9 Start SP 1
Let SCANport device 1 control
starts.
10 Start SP 2
Let SCANport device 2 control
starts.
11 Start SP 3
Let SCANport device 3 control
starts.
Bit Description
12 Start SP 4
Let SCANport device 4 control
starts.
13 Start SP 5
Let SCANport device 5 control
starts.
14 Start SP 6
Let SCANport device 6 control
starts.
15 Start P197
Let Logic Cmd Input
(parameter 197) control starts.
