User Manual V 1-4.XX User guide

Parameters 11-39
122 Pulse In Offset
Enter the minimum speed the pulse input will go to.
Parameter number 122
File:group Interface/Comm:Digital Config
Parameter type destination
Display ±x.x rpm
Factory default +0.0
Minimum value -base motor speed
Maximum value +base motor speed
Conversion 4096 = base motor speed
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
123 Pulse In Value
Use Pulse In Value to view the pulse input value. You need to link
Pulse In Value to a reference parameter.
Parameter number 123
File:group Interface/Comm:Digital Config
Parameter type source
Display ±x.x rpm
Factory default not applicable
Minimum value 0.0
Maximum value +8 x base motor speed
Conversion 4096 = base motor speed
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
124 SP Enable Mask
Use SP Enable Mask to select which SCANport devices can
control the drive. You can choose between:
0 = Disable control
1 = Enable control
Stop is always active, even if you disable a device.
The bits are defined as follows:
Parameter number 124
File:group Interface/Comm:SCANport Config
Parameter type linkable destination
Display bits
Factory default 11111111
Minimum value 00000000
Maximum value 11111111
Conversion 1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit Description
0 Enable L Opt
Enable the L Option board.
1 Enable SP 1
Enable SCANport device 1.
2 Enable SP 2
Enable SCANport device 2.
Bit Description
3 Enable SP 3
Enable SCANport device 3.
4 Enable SP 4
Enable SCANport device 4.
5 Enable SP 5
Enable SCANport device 5.
Bit Description
6 Enable SP 6
Enable SCANport device 6.
7 Enable P197
Enable Logic Cmd Input
(parameter 197).
