11-38 Parameters
117 L Option In Sts
Use L Option In Sts to view the status of the L Option inputs.
Parameter number 117
File:group Interface/Comm:Digital Config
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 00000001.11111111
Conversion 1 = 1
Bit Description Bit Description Bit Description Bit Description
0 TB3-19 3 TB3-23 6 TB3-27 9 – 15 Reserved
1 TB3-20 4 TB3-24 7 TB3-28 Leave 0.
2 TB3-22 5 TB3-26 8 TB3-30 (enable)
118 Mop Increment
Use Mop Increment to set the rate of increase or decrease to the
Manually Operated Potentiometer (MOP) value based on
rpm/second. Mop Increment is only used when the value of
L Option Mode (parameter 116) is 5, 9, 10, or 15.
Parameter number 118
File:group Interface/Comm:Digital Config
Parameter type linkable destination
Display x.x rpm (rpm/second)
Factory default 10% of base motor speed
Minimum value 0.0
Maximum value base motor speed
Conversion 4096 = base motor speed
Refer to Chapter 9, Applications, for more information.
119 Mop Value
Use Mop Value to view the Manually Operated Potentiometer
(MOP) value. You need to link Mop Value to a reference, such as
Speed Ref 1 (parameter 29) for the drive to follow the Mop
command for speed.
Parameter number 119
File:group Interface/Comm:Digital Config
Parameter type source
Display ±x.x rpm
Factory default not applicable
Minimum value 0.0
Maximum value base motor speed
Conversion 4096 = base motor speed
Refer to Chapter 9, Applications, for more information.
120 Pulse In PPR
Use Pulse In PPR to set the number of pulses per revolution.
Parameter number 120
File:group Interface/Comm:Digital Config
Parameter type destination
Display x PPR
Factory default 1024
Minimum value 500
Maximum value 20000
Conversion 1 = 1
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
121 Pulse In Scale
Enter the value to use to scale the pulse input. The scale is a
ratio. For example, you would enter 0.5 if you want to scale the
pulse input to half.
Parameter number 121
File:group Interface/Comm:Digital Config
Parameter type destination
Display x.xx
Factory default 1.00
Minimum value 0.01
Maximum value 10.00
Conversion 100 = 1.00
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
