Parameters 11-37
115 Relay Setpoint 1
Relay Setpoint 1 lets you specify the setpoint threshold for either
speed or current. Relay Setpoint 1 is only active if Relay Config 1
(parameter 114) is set to a value of 25, 26, 27, or 28.
Parameter number 115
File:group Interface/Comm:Digital Config
Parameter type linkable destination
Display ±x.x%
Factory default +0.0%
Minimum value -800.0%
Maximum value +800.0%
Conversion 4096 = 100.0%
116 L Option Mode
Use L Option Mode to select the functions of L Option inputs at
TB3. If you change the value of L Option Mode, you must cycle
power before the change will take effect.
The following is the mode information:
Parameter number 116
File:group Interface/Comm:Digital Config
Parameter type destination
Display x
Factory default 1
Minimum value 1
Maximum value 32
Conversion 1 = 1
Refer to Chapter 5, Using the L Option, for additional information.
Mode TB3-19 TB3-20 TB3-22 TB3-23
1 Status Stop Status Status
2 Start Stop Rev/Fwd Jog
3 Start Stop Rev/Fwd 2/1Stop Type
4 Start Stop Rev/Fwd 2/1 Accel
5 Start Stop Rev/Fwd Pot Up
6 Start Stop Rev/Fwd Jog
7 Start Stop Rev Fwd
8 Start Stop Rev Fwd
9 Start Stop Pot Up Pot Dn
10 Start Stop Rev Fwd
11 Start Stop 1st Accel 2nd Accel
12 Run Fwd Stop Run Rev Loc/Rem
13 Run Fwd Stop Run Rev 2/1 Stop Type
14 Run Fwd Stop Run Rev 2/1 Accel
15 Run Fwd Stop Run Rev Pot Up
16 Run Fwd Stop Run Rev Loc/Rem
17 Start Stop Rev/Fwd Proc Trim
18 Start Stop Rev/Fwd Flux En
19 Start Stop Spd/Trq 3 Spd/Trq 2
20 Start Stop Spd/Trq 3 Spd/Trq 2
21 Start Stop Rev Fwd
22 Start Stop Spd/Trq 3 Spd/Trq 2
23 Run Fwd Stop Run Rev Proc Trim
24 Run Fwd Stop Run Rev Flux En
25 Run Fwd Stop Run Rev Proc Trim
26
1
Run Fwd Stop Run Rev Jog
27
2
Start Stop Rev/Fwd Pot Up
28
2
Start Stop Pot Up Pot Dn
29
2
Start Stop Rev Fwd
30
2
Run Fwd Stop Run Rev Pot Up
31
3
Step Trigger Not Stop Step Trigger Step Trigger
32
3
Start Not Stop Step Trigger Step Trigger
1 Added for Version 2.01.
2 Added for Version 2.02
3 Added for Version 4.01
TB3-24 TB3-26 TB3-27 TB3-28
Status Status Status Status
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault 2/1 Decel Spd 2 Spd 1
Ext Fault Pot Dn Spd 2 Spd 1
Ext Fault Loc/Rem Spd 2 Spd 1
Ext Fault Jog Spd 2 Spd 1
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault Pot Up Pot Dn Spd 1
Ext Fault 1st Decel 2nd Decel Spd 1
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault 2/1 Decel Spd 2 Spd 1
Ext Fault Pot Dn Spd 2 Spd 1
Ext Fault 2/1 Stop Type Spd 2 Spd 1
Ext Fault Ramp Spd 2 Spd 1
Ext Fault Reset Spd 2 Spd 1
Ext Fault Spd/Trq 1 Proc Trim Spd 1
Ext Fault Spd/Trq 1 Flux En Spd 1
Ext Fault Ramp Reset Spd 1
Ext Fault Spd/Trq 1 Spd 2 Spd 1
Ext Fault Reset Spd 2 Spd 1
Ext Fault Reset Spd 2 Spd 1
Ext Fault Ramp Spd 2 Spd 1
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault Pot Dn Spd 2 Spd 1
Ext Fault Spd 3 Spd 2 Spd 1
Ext Fault Pot Up Pot Dn Spd 1
Ext Fault Pot Dn Spd 2 Spd 1
Not Ext Flt Step Trigger Step Trigger Step Trigger
Not Ext Flt Profile Enable Run SequenceStep Hold
