Parameters 11-35
106 An Out 1 Offset
Use An Out 1 Offset to set the offset applied to the raw analog
output 1. The offset is applied after the scale factor.
Parameter number 106
File:group Interface/Comm:Analog Outputs
Parameter type linkable destination
Display ±x.xxx volts
Factory default +0.000 volts
Minimum value -20.000 volts
Maximum value +20.000 volts
Conversion 205 = 1.000
107 An Out 1 Scale
Use An Out 1 Scale to set the scale factor or gain for analog
output 1. A +32767 digital value is converted by the scale factor.
This allows an effective digital range of +2048 which is then
offset to provide a +10 volt range.
Parameter number 107
File:group Interface/Comm:Analog Outputs
Parameter type linkable destination
Display ±x.xxx
Factory default +0.500
Minimum value -1.000
Maximum value +1.000
Conversion 32767 = 1.000
108 An Out 2 Value
Use An Out 2 Value to convert a +32767 digital value to a +10
volt output. This is the value of the analog output number 2.
Parameter number 108
File:group Interface/Comm:Analog Outputs
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
109 An Out 2 Offset
Use An Out 2 Offset to set the offset applied to the raw analog
output 2. The offset is applied after the scale factor.
Parameter number 109
File:group Interface/Comm:Analog Outputs
Parameter type linkable destination
Display ±x.xxx volts
Factory default +0.000 volts
Minimum value -19.980 volts
Maximum value +19.980 volts
Conversion 205 = 1.000
110 An Out 2 Scale
Use An Out 2 Scale to set the scale factor or gain for analog
output 2. A +32767 digital value is converted by the scale factor.
This allows an effective digital range of +2048 which is then
offset to provide a +10 volt range.
Parameter number 110
File:group Interface/Comm:Analog Outputs
Parameter type linkable destination
Display ±x.xxx
Factory default +0.500
Minimum value -1.000
Maximum value +1.000
Conversion 32767 = 1.000
111 mA Out Value
Use mA Out Value to convert a +32767 digital value to a
4 – 20 mA output. This is the value of the mA output.
Parameter number 111
File:group Interface/Comm:Analog Outputs
Parameter type linkable destination
Display ±x
Factory default +0
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
