Parameters 11-33
If you enter this value for Test
Select 2 (parameter 95):
Then, the value in Test Data 2 (parameter 94) represents the:
hours
minutes/seconds
11124 11224 The time since power up that the fault in position 24 occurred
11125 11225 The time since power up that the fault in position 25 occurred
11126 11226 The time since power up that the fault in position 26 occurred
11127 11227 The time since power up that the fault in position 27 occurred
11128 11228 The time since power up that the fault in position 28 occurred
11129 11229 The time since power up that the fault in position 29 occurred
11130 11230 The time since power up that the fault in position 30 occurred
11131 11231 The time since power up that the fault in position 31 occurred
11132 11232 The time since power up that the fault in position 32 occurred
58144 Drive software version (example: 101)
58146 Drive power structure type
58220 Speed regulator output
58228 Speed error (reference — feedback)
58230 Unfiltered speed feedback (4096 @ Nameplate RPM)
58250 Internal torque reference (4096 @ rated motor torque)
58296 Inverter temperature feedback (degrees Celsius)
96 An In 1 Value
Use An In 1 Value to view the converted analog value of the input
at analog input 1.
Parameter number 96
File:group Interface/Comm:Analog Inputs
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
97 An In 1 Offset
Use An In 1 Offset to set the offset applied to the raw analog
value of the analog input 1 before the scale factor is applied. This
lets you shift the range of the analog input.
Parameter number 97
File:group Interface/Comm:Analog Inputs
Parameter type linkable destination
Display ±x.xxx volts
Factory default 0.000 volts
Minimum value -19.980 volts
Maximum value +19.980 volts
Conversion 205 = 1.000
98 An In 1 Scale
Use An In 1 Scale to set the scale factor or gain for analog
input 1. The value of analog input 1 is converted to +2048 and
then the scale is applied. This provides an effective digital range
of ±32767.
Parameter number 98
File:group Interface/Comm:Analog Inputs
Parameter type linkable destination
Display ±x.xxx
Factory default +2.000
Minimum value -16.000
Maximum value +16.000
Conversion 2048 = 1.000
99 An In 2 Value
Use An In 2 Value to view the converted analog value of the input
at analog input 2.
Parameter number 99
File:group Interface/Comm:Analog Inputs
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32767
Maximum value +32767
Conversion 1 = 1
