11-32 Parameters
95 Test Select 2
Test Select 2 is a diagnostic tool that you can use to access
specific testpoints. The value you enter specifies which data
values should be displayed in Test Data 2 (parameter 94). For
Test Select 2 values of 11100 through 11232, you need to first
enter a 111xx value to determine the number of hours since
power up, and then enter a 112xx value to determine the number
of minutes and seconds since power up.
Parameter number 95
File:group Monitor:Testpoints
Fault Setup:Testpoints
Parameter type linkable destination
Display x
Factory default 0
Minimum value 0
Maximum value 65535
Conversion 1 = 1
If you enter this value for
Test Select 2 (parameter 95):
Then, the value in Test Data 2 (parameter 94) represents the:
9728 Scaled version of Torque Ref 1 (parameter 69)
9730 Sum of scaled Torque Ref 1 (parameter 69) and PTrim Output (parameter 48)
9987 Upper current limit (4096 @ rated motor positive current)
9988 Lower current limit (-4096 @ rated motor negative current)
9990 Upper torque limit (4096 @ rated motor positive torque)
9991 Lower torque limit (-4096 @ rated motor negative torque)
10000 Motor Flux % (parameter 88) limited to Min Flux Level (parameter 71)
10264 Value of Logic Input Status (par 14) at the time of the last stop event.
10503 Parameter limit conditions
10504 Parameter limit conditions
10505 Speed reference math limits
10506 Speed feedback math limits
10507 Speed regulator math limits
10508 Torque reference math limits
10509 Process trim math limits
hours minutes/seconds
11100 11200 Realtime accumulated since power up
11101 11201 The time since power up that the fault in position 1 occurred
11102 11202 The time since power up that the fault in position 2 occurred
11103 11203 The time since power up that the fault in position 3 occurred
11104 11204 The time since power up that the fault in position 4 occurred
11105 11205 The time since power up that the fault in position 5 occurred
11106 11206 The time since power up that the fault in position 6 occurred
11107 11207 The time since power up that the fault in position 7 occurred
11108 11208 The time since power up that the fault in position 8 occurred
11109 11209 The time since power up that the fault in position 9 occurred
11110 11210 The time since power up that the fault in position 10 occurred
11111 11211 The time since power up that the fault in position 11 occurred
11112 11212 The time since power up that the fault in position 12 occurred
11113 11213 The time since power up that the fault in position 13 occurred
11114 11214 The time since power up that the fault in position 14 occurred
11115 11215 The time since power up that the fault in position 15 occurred
11116 11216 The time since power up that the fault in position 16 occurred
11117 11217 The time since power up that the fault in position 17 occurred
11118 11218 The time since power up that the fault in position 18 occurred
11119 11219 The time since power up that the fault in position 19 occurred
11120 11220 The time since power up that the fault in position 20 occurred
11121 11221 The time since power up that the fault in position 21 occurred
11122 11222 The time since power up that the fault in position 22 occurred
11123 11223 The time since power up that the fault in position 23 occurred
