Parameters 11-31
91 Iq %
Iq % shows the value of torque current reference that is present
at the output of the current rate limiter. 100% is equal to 1 per unit
(pu) rated motor torque.
Parameter number 91
File:group none
Parameter type source
Display ±x.x%
Factory default not applicable
Minimum value -800.0%
Maximum value +800.0%
Conversion 4096 = 100.0%
92 Test Data 1
Use Test Data 1 to view a data value that corresponds to the
value selected in Test Select 1 (parameter 93). Test Data 1 is a
diagnostic tool used to view internal drive parameters.
Parameter number 92
File:group Monitor:Testpoints
Fault Setup:Testpoints
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32768
Maximum value +32767
Conversion 1 = 1
93 Test Select 1
Test Select 1 is a diagnostic tool that you can use to access
specific test points. The value you enter specifies which data
value should be displayed in Test Data 1 (parameter 92).
Parameter number 93
File:group Monitor:Testpoints
Fault Setup:Testpoints
Parameter type linkable destination
Display x
Factory default 0
Minimum value 0
Maximum value 65535
Conversion 1 = 1
If you enter this value for Test Select 1
(parameter 93):
Then, the value in Test Data 1 (parameter 92) represents the:
12 Precharge status
86 Approximate fluxing time
94 Test Data 2
Use Test Data 2 to view a data value that corresponds to the
value selected in Test Select 2 (parameter 95). Test Data 2 is a
diagnostic tool used to view internal parameters.
Parameter number 94
File:group Monitor:Testpoints
Fault Setup:Testpoints
Parameter type source
Display ±x
Factory default not applicable
Minimum value -32768
Maximum value +32767
Conversion 1 = 1
