11-30 Parameters
87 Torque Limit Sts
Use Torque Limit Sts to view a bit-coded summary of any
condition that may be limiting either the current or the torque
reference.
The bits are defined as follows:
Parameter number 87
File:group Monitor:Drive/Inv Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 01111111.11111111
Conversion 1 = 1
Refer to Appendix B, Control Block Diagrams, for more
information on the NTC and IT inverter foldbacks.
Value Description
0 +Mtr Iq Lim
Positive motor current limit
1 +NTC Foldbak
Positive NTC inverter foldback
2 +IT Foldback
Positive IT inverter foldback
3 +Flux Brake
Iq limited due to flux braking.
4 +Torque Lim
Positive torque limit
5 +Trq Pwr Lim
Positive torque power limit
Value Description
6 +Atune Trq
Positive auto-tune torque
7 Reserved
Leave 0.
8 -Mtr Iq Lim
Negative motor current limit
9 -NTC Foldbak
Negative NTC inverter protection
foldback
10 -IT Foldback
IT inverter protection foldback
11 -Flux Brake
Iq limited due to flux braking.
Value Description
12 -Torque Lim
Negative torque limit
13 -Trq Pwr Lim
Negative torque power limit
14 -Atune Trq
Negative auto-tune torque limit
15 Reserved
Leave 0.
88 Motor Flux %
Use Motor Flux % to view the level of motor field flux calculated
by the drive.
Parameter number 88
File:group Monitor:Motor Status
Parameter type source
Display x.x%
Factory default not applicable
Minimum value 12.5%
Maximum value 100.0%
Conversion 4096 = 100.0%
89 Motor Frequency
Use Motor Frequency to view the actual value of motor stator
frequency in Hz.
Parameter number 89
File:group Monitor:Motor Status
Parameter type source
Display x.xxx Hz
Factory default not applicable
Minimum value -250.000 Hz
Maximum value +250.000 Hz
Conversion 128 = 1.000
90 Motor Power %
Motor Power % is the calculated product of torque reference
times motor speed feedback. A 125 millisecond filter is applied to
this result. Positive values indicate motoring power; negative
values indicate regenerative power.
Parameter number 90
File:group Monitor:Motor Status
Parameter type source
Display ±x.x% PWR
Factory default not applicable
Minimum value -800.0%
Maximum value +800.0%
Conversion 4096 = 100.0%
