Parameters 11-29
83 Motor Current
Use Motor Current to view the actual RMS value of the motor
current as determined from the LEM current sensors. This data is
averaged and updated every 50 milliseconds.
Parameter number 83
File:group Monitor:Motor Status
Parameter type source
Display x.x amp
Factory default not applicable
Minimum value 0.0 amps
Maximum value 6553.5 amps
Conversion 4096 = rated inverter amps
84 DC Bus Voltage
DC Bus Voltage represents the actual bus voltage in volts as
read by the software from an analog input port.
Parameter number 84
File:group Monitor:Drive/Inv Status
Parameter type source
Display x volts
Factory default not applicable
Minimum value 0 volts
Maximum value 1000 volts
Conversion 1 = 1
85 Motor Voltage
Use Motor Voltage to view the actual line-to-line fundamental
RMS value of motor voltage. This data is averaged and updated
every 50 milliseconds.
Parameter number 85
File:group Monitor:Motor Status
Parameter type source
Display x volt
Factory default not applicable
Minimum value 0 volts
Maximum value +3000 volts
Conversion 1 = 1
86 Motor Torque %
Use Motor Torque % to view the calculated value of motor torque
as determined by the drive. The actual value of the motor torque
is within 5% of this value. This data is updated every
2 milliseconds.
Parameter number 86
File:group Monitor:Motor Status
Parameter type source
Display ±x.x% trq
Factory default not applicable
Minimum value -800.0%
Maximum value +800.0%
Conversion 4096 = 100.0%
