Parameters 11-23
55 PTrim Kp
Use PTrim Kp to control the proportional gain of the process trim
regulator. If the Kp process trim is equal to 1.0, the process trim
PI regulator output equals 1 pu for 1 pu process trim error.
Parameter number 55
File:group Application:Process Trim
Parameter type linkable destination
Display x.xxx
Factory default 1.000
Minimum value 0.000
Maximum value 16.000
Conversion 4096 = 1.000
Refer to the Trim Control Overview section in Appendix B,
Control Block Diagrams, for more information.
56 Reserved
Leave this parameter set to 0.
Parameter number 56
File:group
Parameter type
Display
Factory default
Minimum value
Maximum value
Conversion
57 Reserved
Leave this parameter set to 0.
Parameter number 57
File:group
Parameter type
Display
Factory default
Minimum value
Maximum value
Conversion
58 PTrim Lo Limit
Use PTrim Lo Limit to specify the low limit of the process trim
regulator output value. The output of the process trim regulator is
limited by adjustable high and low limits.
Parameter number 58
File:group Application:Process Trim
Parameter type linkable destination
Display ±x.x%
Factory default -100.0%
Minimum value -800.0%
Maximum value +800.0%
Conversion 4096 = 100.0%
Refer to the Trim Control Overview section in Appendix B,
Control Block Diagrams, for more information.
59 PTrim Hi Limit
Use PTrim Hi Limit to specify the high limit of the process trim
regulator output value. The output of the process trim regulator is
limited by adjustable high and low limits.
Parameter number 59
File:group Application:Process Trim
Parameter type linkable destination
Display ±x.x%
Factory default +100.0%
Minimum value -800.0%
Maximum value +800.0%
Conversion 4096 = 100.0%
Refer to the Trim Control Overview section in Appendix B,
Control Block Diagrams, for more information.
