11-20 Parameters
40 Rev Speed Limit
Use Rev Speed Limit to set a limit on speed in the negative
direction. Enter a negative value or zero.
Parameter number 40
File:group Control:Control Limits
Parameter type destination
Display -x.x rpm
Factory default -base motor speed rpm
Minimum value -6 x base motor speed rpm
Maximum value 0.0 rpm
Conversion -4096 = base motor speed
41 Fwd Speed Limit
Use Fwd Speed Limit to set a limit on speed in the positive
direction. Enter a positive value or zero.
Parameter number 41
File:group Control:Control Limits
Parameter type destination
Display x.x rpm
Factory default +base motor speed rpm
Minimum value 0.0 rpm
Maximum value +6 x base motor speed rpm
Conversion +4096 = base motor speed
42 Accel Time 1
Enter the length of time for the drive to ramp from 0 rpm to the
base speed.
Parameter number 42
File:group Control:Accel/Decel
Parameter type linkable destination
Display x.x seconds
Factory default 5.0 seconds
Minimum value 0.0 seconds
Maximum value 6553.5 seconds
Conversion 10 = 1.0
43 Accel Time 2
Enter the length of time for the drive to ramp from 0 rpm to the
base speed. Accel Time 2 is available only when the value of
L Option Mode (parameter 116) is 4, 11, or 14.
Parameter number 43
File:group Control:Accel/Decel
Parameter type linkable destination
Display x.x seconds
Factory default 10.0 seconds
Minimum value 0.0 seconds
Maximum value 6553.5 seconds
Conversion 10 = 1.0
44 Decel Time 1
Enter the length of time for the drive to ramp from base speed to
0 rpm. This is used for a ramp stop.
Parameter number 44
File:group Control:Accel/Decel
Parameter type linkable destination
Display x.x seconds
Factory default 5.0 seconds
Minimum value 0.0 seconds
Maximum value 6553.5 seconds
Conversion 10 = 1.0
45 Decel Time 2
Enter the length of time for the drive to ramp from base speed to
0 rpm. This is used for a ramp stop. Decel Time 2 is available
only when the value of L Option Mode (parameter 116) is 4, 11,
or 14.
Parameter number 45
File:group Control:Accel/Decel
Parameter type linkable destination
Display x.x seconds
Factory default 10.0 seconds
Minimum value 0.0 seconds
Maximum value 6553.5 seconds
Conversion 10 = 1.0
