Parameters 11-19
34 Speed Ref 5
Enter the speed reference that the drive should use when speed
reference 5 is selected in Logic Input Sts (parameter 14).
Parameter number 34
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
35 Speed Ref 6
Enter the speed reference that the drive should use when speed
reference 6 is selected in Logic Input Sts (parameter 14).
Parameter number 35
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
36 Speed Ref 7
Enter the speed reference that the drive should use when speed
reference 7 is selected in Logic Input Sts (parameter 14).
Parameter number 36
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
37 Speed Scale 7
Enter the gain multiplier used to scale Speed Ref 7
(parameter 36).
Parameter number 37
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.xxxx
Factory default +1.0000
Minimum value -3.9999
Maximum value +3.9999
Conversion 8192 = 1.0000
38 Jog Speed 1
Enter the speed reference that the drive should use when Jog 1
is selected in Logic Input Sts (parameter 14).
Parameter number 38
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default +100.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
39 Jog Speed 2
Enter the speed reference that the drive should use when Jog 2
is selected in Logic Input Sts (parameter 14).
Parameter number 39
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
