11-18 Parameters
28 Speed Ref 1 Frac
Use Speed Ref 1 Frac to supply the fractional part of the external
speed reference 1 when speed reference is selected in Logic
Input Sts (parameter 14).
Parameter number 28
File:group none
Parameter type linkable destination
Display x
Factory default 0
Minimum value 0
Maximum value 65535
Conversion 1 = 1/2^28 base motor speed
29 Speed Ref 1
Enter the speed reference that the drive should use when speed
reference 1 is selected in Logic Input Sts (parameter 14). Speed
Ref 1 supplies the whole number portion of the speed reference.
You can use Speed Ref 1 Frac (parameter 28) to specify the
fractional portion of the speed reference.
Parameter number 29
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default 0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
30 Speed Scale 1
Enter the gain multiplier used to scale speed reference 1.
Parameter number 30
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.xxxx
Factory default +1.0000
Minimum value -3.9999
Maximum value +3.9999
Conversion 8192 = 1.0000
31 Speed Ref 2
Enter the speed reference that the drive should use when speed
reference 2 is selected in Logic Input Sts (parameter 14).
Parameter number 31
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default 0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
32 Speed Ref 3
Enter the speed reference that the drive should use when speed
reference 3 is selected in Logic Input Sts (parameter 14).
Parameter number 32
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
33 Speed Ref 4
Enter the speed reference that the drive should use when speed
reference 4 is selected in Logic Input Sts (parameter 14).
Parameter number 33
File:group Control:Speed Reference
Parameter type linkable destination
Display ±x.x rpm
Factory default +0.0 rpm
Minimum value -8 x base motor speed rpm
Maximum value +8 x base motor speed rpm
Conversion 4096 = base motor speed
