Parameters 11-15
19 Zero Speed Tol
Use Zero Speed Tol to establish a band around zero speed that
is used to determine when the drive considers the motor to be at
zero speed. Bit 12 (At Zero Spd) in Drive/Inv Status
(parameter 15) indicates this.
Parameter number 19
File:group Control:Drive Logic Select
Parameter type linkable destination
Display x.x rpm
Factory default base motor speed/100 rpm
Minimum value 0.0 rpm
Maximum value 8 x base motor speed rpm
Conversion 4096 = base motor speed
20 Fault Select 1
Use Fault Select 1 to specify how the drive should handle certain
conditions. Each bit within this parameter matches the bit
definitions of Warning Select 1 (parameter 21). If you set bit(s)
to 1 in this parameter, the drive reports a fault when that
condition occurs. If you clear bit(s) to 0, the drive reports the
condition based on Warning Select 1.
The bits are defined as follows:
Parameter number 20
File:group Fault Setup:Fault Config
Parameter type linkable destination
Display bits
Factory default 01111110.00100011
Minimum value 00000000.00000000
Maximum value 01111111.00111111
Conversion 1 = 1
Refer to Chapter 12, Troubleshooting, for additional information.
Bit Description
0 RidethruTime
A bus ridethrough timeout
occurred.
1 Prechrg Time
A bus precharge timeout
occurred.
2 Bus Drop
A bus drop of 150 volts occurred.
3 Bus Undervlt
A bus undervoltage occurred.
4 Bus Cycles>5
More than 5 ridethroughs
occurred in a row.
5 Open Circuit
Fast flux up current is <50%.
Bit Description
6 – 7 Reserved
Leave 0.
8 mA Input
A loss of input connection
occurred after it was established.
9 SP 1 Timeout
Loss of communication with
SCANport device 1 occurred.
10 SP 2 Timeout
Loss of communication with
SCANport device 2 occurred.
11 SP 3 Timeout
Loss of communication with
SCANport device 3 occurred.
Bit Description
12 SP 4 Timeout
Loss of communication with
SCANport device 4 occurred.
13 SP 5 Timeout
Loss of communication with
SCANport device 5 occurred.
14 SP 6 Timeout
Loss of communication with
SCANport device 6 occurred.
15 SP Error
Too many errors on the
SCANport communication.
