14 Logic Input Sts
Use Logic Input Sts to view drive logic operation. If a bit is set (1),
that function is enabled. If a bit is clear (0), that function is
disabled (not active).
The bits are defined as follows:
Parameter number 14
File:group Monitor:Drive/Inv Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
Bit Description
0 Normal Stop
A ramp stop is selected.
1 Start
A start is in progress.
2 Jog 1
A jog 1 is in progress.
3 Clear Fault
A clear fault is in progress.
4 Forward
A forward was commanded.
Bit Description
5 Reverse
A reverse was commanded.
6 Jog 2
A jog 2 is in progress.
7 Cur Lim Stop
A current limit stop is
selected.
8 Coast Stop
A coast stop is selected.
9 Spd Ramp Dis
Ramps are disabled.
Bit Description
10 Flux Enable
Flux is enabled.
11 Process Trim
Process trim is enabled.
12 Speed Ref A
13 Speed Ref B
14 Speed Ref C
15 Reset Drive
The drive has been
commanded to reset.
CBA
0 0 0 No Change
0 0 1 Speed Ref 1
0 1 0 Speed Ref 2
0 1 1 Speed Ref 3
1 0 0 Speed Ref 4
1 0 1 Speed Ref 5
1 1 0 Speed Ref 6
1 1 1 Speed Ref 7
15 Drive/Inv Status
Use Drive/Inv Status to view the status/conditions within the
drive. When a bit is set (1), the corresponding condition in the
drive is true.
The bits are defined as follows:
Parameter number 15
File:group Monitor:Drive/Inv Status
Parameter type source
Display bits
Factory default not applicable
Minimum value 00000000.00000000
Maximum value 11111111.11111111
Conversion 1 = 1
1 If a warning has occurred, check the warning queue for more information.
2 If a fault has occurred, check the fault queue for more information.
CBA
0 0 0 No Change
0 0 1 Speed Ref 1
0 1 0 Speed Ref 2
0 1 1 Speed Ref 3
1 0 0 Speed Ref 4
1 0 1 Speed Ref 5
1 1 0 Speed Ref 6
1 1 1 Speed Ref 7
Bit Description
0 Run Ready
The drive is ready to run. No
bits are set in Run Inhibit Sts
(parameter 16)
1 Running
The drive is following a
speed/torque reference
2 Command Dir
Shows which direction has
been requested; 1 is forward,
and 0 is reverse.
3 Rotating Dir
Shows the direction that the
motor is currently rotating; 1
is forward, and 0 is reverse.
Bit Description
4 Accelerating
If 1, the motor is accelerating.
5 Decelerating
If 1, the motor is decelerating.
6 Warning
If 1, a warning has occurred.
1
7 Faulted
If 1, a fault has occurred.
2
8 At Set Speed
The motor is at the requested
speed.
9 Enable LED
The drive is enabled.
Bit Description
10 Stopped
If 1, the drive is stopped.
11 Stopping
If 1, the drive is stopping.
12 At Zero Spd
Corresponds to Zero Speed
To l (parameter 19).
13 Speed Ref A
14 Speed Ref B
15 Speed Ref C
