Parameters 11-11
7 Motor Poles
Motor Poles contains the number of motor poles. The drive
calculates this value during the Quick Motor Tune portion of the
start up routine.
Note: Encoder PPR
Parameter number 7
File:group Motor/Inverter:Motor Nameplate
Motor/Inverter:Motor Constants
Parameter type destination
Display x poles
Factory default 4 poles
Minimum value 2 poles
Maximum value 40 poles
Conversion 1 = 1
8 Encoder PPR
Encoder PPR contains the pulse per revolution rating of the
feedback device when you use an encoder to determine motor
speed.
Note: Encoder PPR
Parameter number 8
File:group Motor/Inverter:Encoder Data
Control:Feedback Device
Parameter type destination
Display x ppr
Factory default 1024 ppr
Minimum value calculated
Maximum value 20000 ppr
Conversion 1 = 1
9 Service Factor
Enter the minimum level of current that causes a motor overload
(I
2
T) trip under continuous operation. Current levels below this
value never result in an overload trip. For example, a service
factor of 1.15 implies continuous operation up to 115% of
nameplate motor current.
Parameter number 9
File:group Motor/Inverter:Motor Nameplate
Parameter type destination
Display x.xx
Factory default 1.15
Minimum value 1.00
Maximum value 2.00
Conversion 4096 = 1.00
10 PWM Frequency
Enter the drive carrier frequency in Hz. The drive carrier
frequency depends on your application and drive size. The drive
carrier frequency affects the audible noise level of your motor.
Parameter number 10
File:group Motor/Inverter:Inverter
Parameter type destination
Display x Hz
Factory default 4000 Hz
Minimum value 1000 Hz
Maximum value from the drive type
Conversion 1 = 1
11 Inverter Amps
Inverter Amps provides the current rating of the inverter. The
drive automatically sets Inverter Amps at power up.
Parameter number 11
File:group Motor/Inverter:Inverter
Parameter type source
Display x.x amps
Factory default not applicable
Minimum value 0.1 amps
Maximum value from drive type
Conversion 10 = 1.0
12 Inverter Volts
Inverter Volts is the drive nameplate voltage rating of the inverter.
The drive automatically sets Inverter Volts at power up.
Parameter number 12
File:group Motor/Inverter:Inverter
Parameter type source
Display x volts
Factory default not applicable
Minimum value 75 volts
Maximum value 575 volts
Conversion 1 = 1
# of Motor Poles
Must be greater than 64
# of Motor Poles
Must be greater than 64
