11-10 Parameters
1 Language Select
Use Language Select to choose between a primary language
and an alternate language. Select:
• 0 to choose the primary language
• 1 to choose the alternate language
Parameter number 1
File:group none
Parameter type linkable destination
Display x
Factory default 0
Minimum value 0
Maximum value 1
Conversion 1 = 1
2 Nameplate HP
Nameplate HP contains the value of the motor horsepower that
you entered during the start up routine. This value is typically
located on the motor nameplate.
Parameter number 2
File:group Motor/Inverter:Motor Nameplate
Parameter type destination
Display x .x hp
Factory default 30.0 hp
Minimum value 0.2 hp
Maximum value 2000.0 hp
Conversion 10 = 1.0
3 Nameplate RPM
Nameplate RPM contains the value of the motor speed that you
entered during the start up routine. This value is typically located
on the motor nameplate. This value should not be the
synchronous speed of the motor.
Parameter number 3
File:group Motor/Inverter:Motor Nameplate
Parameter type destination
Display x rpm
Factory default 1750 rpm
Minimum value 1 rpm
Maximum value 15000 rpm
Conversion 1 = 1
4 Nameplate Amps
Nameplate Amps contains the value of the current rating of the
motor that you entered during the start up routine. This value is
typically located on the motor nameplate. The drive uses this
information to properly tune to the motor.
Parameter number 4
File:group Motor/Inverter:Motor Nameplate
Parameter type destination
Display x.x amps
Factory default 0.2 amps
Minimum value 0.1 amps
Maximum value calculated
Conversion 10 = 1.0
5 Nameplate Volts
Nameplate Volts contains the voltage rating of the motor that you
entered during the start up routine. This value is typically located
on the motor nameplate.
Parameter number 5
File:group Motor/Inverter:Motor Nameplate
Parameter type destination
Display x volt
Factory default 460 volts
Minimum value 75 volts
Maximum value 575 volts
Conversion 1 = 1
6 Nameplate Hz
Nameplate Hz contains the value of the frequency rating of the
motor that you entered during the start up routine. This value is
typically located on the motor nameplate.
Parameter number 6
File:group Motor/Inverter:Motor Nameplate
Parameter type destination
Display x.x Hz
Factory default 60.0 Hz
Minimum value 1.0 Hz
Maximum value 250.0 Hz
Conversion 10 = 1.0
