11-8 Parameters
Nameplate Hz 6 11-10 Slave Torque % 70 11-26 Step 7 Speed 267 11-79
Nameplate RPM 3 11-10 Slip Gain 169 11-50 Step 7 Value 268 11-79
Nameplate Volts 5 11-10 SP 2 Wire Enable 181 11-26 Step 7 Type 269 11-80
Ncfg Flt Status 220 11-70 SP An In1 Scale 135 11-50 Step 8 Speed 270 11-80
Neg Mtr Cur Lim 73 11-27 SP An In1 Select 133 11-54 Step 8 Value 271 11-80
Neg Torque Lim 75 11-27 SP An In1 Value 134 11-44 Step 8 Type 272 11-80
Notch Filtr Freq 185 11-55 SP An In2 Scale 138 11-44 Step 9 Speed 273 11-80
Notch Filtr Q 186 11-55 SP An In2 Select 136 11-44 Step 9 Value 274 11-80
Pos Mtr Cur Lim 72 11-27 SP An In2 Value 137 11-45 Step 9 Type 275 11-80
Pos Torque Lim 74 11-27 SP An Output 139 11-44 Step 10 Speed 276 11-81
Profile Enable 235 2-72 SP Enable Mask 124 11-44 Step 10 Value 277 11-81
Profile Status 236 2-72 Spd Desired BW 161 11-45 Step 10 Type 278 11-81
PTrim Feedback 50 11-21 Spd Error 226 11-39 Step 11 Speed 279 11-81
PTrim Filter BW 52 11-22 Spd Reg Output 225 11-49 Step 11 Value 280 11-81
PTrim Hi Limit 59 11-23 Spd/Trq Mode Sel 68 11-72 Step 11 Type 281 11-81
PTrim Ki 54 11-22 Speed Ref 1 29 11-72 Step 12 Speed 282 11-82
PTrim Kp 55 11-23 Speed Ref 1 Frac 28 11-26 Step 12 Value 283 11-82
PTrim Lo Limit 58 11-23 Speed Ref 2 31 11-18 Step 12 Type 284 11-82
PTrim Out Gain 60 11-24 Speed Ref 3 32 11-18 Step 13 Speed 285 11-82
PTrim Output 48 11-21 Speed Ref 4 33 11-18 Step 13 Value 286 11-82
PTrim Preload 53 11-22 Speed Ref 5 34 11-18 Step 13 Type 287 11-82
PTrim Reference 49 11-21 Speed Ref 6 35 11-18 Step 14 Speed 288 11-83
PTrim Select 51 11-22 Speed Ref 7 36 11-19 Step 14 Value 289 11-83
Pulse In Offset 122 11-39 Speed Scale 1 30 11-19 Step 14 Type 290 11-83
Pulse In PPR 120 11-38 Speed Scale 7 37 11-19 Step 15 Speed 291 11-83
Pulse In Scale 121 11-38 Start Dwell Spd 193 11-18 Step 15 Value 292 11-83
Pulse In Value 123 11-39 Start Dwell Time 194 11-19 Step 15 Type 293 11-83
PWM Frequency 10 11-11 Start/Jog Mask 126 11-59 Step 16 Speed 294 11-84
PwrUp Flt Status 219 11-70 Start/Stop Owner 129 11-59 Step 16 Value 295 11-84
Ramp/ClFlt Owner 131 11-43 Stator Resistnce 166 11-40 Step 16 Type 296 11-84
Regen Power Lim 76 11-27 Step 1 Speed 249 11-42 Stop Dwell Time 18 11-14
Relay Config 1 114 11-36 Step 1 Value 250 11-50 Test Data 1 92 11-31
Relay Config 2 187 11-56 Step 1 Type 251 11-76 Test Data 2 94 11-31
Relay Config 3 189 11-57 Step 2 Speed 252 11-77 Test Select 1 93 11-31
Relay Config 4 191 11-58 Step 2 Value 253 11-77 Test Select 2 95 11-32
Relay Setpoint 1 115 11-37 Step 2 Type 254 11-77 Torque Limit Sts 87 11-30
Relay Setpoint 2 188 11-56 Step 3 Speed 255 11-77 Torque Ref 1 69 11-26
Relay Setpoint 3 190 11-57 Step 3 Value 256 11-77 Total Inertia 157 11-48
Relay Setpoint 4 192 11-58 Step 3 Type 257 11-77 Trans Dgn Config 172 11-51
Reserved 163 11-49 Step 4 Speed 258 11-77 Units Traveled 246 11-76
Reserved 56 11-23 Step 4 Value 259 11-77 Value Tolerance 244 11-75
Reserved 57 11-23 Step 4 Type 260 11-70 Vd Max 170 11-51
Reserved 218 11-70 Step 5 Speed 261 11-78 Vq Max 171 11-51
Rev Speed Limit 40 11-20 Step 5 Value 262 11-78 Warning Select 1 21 11-16
Run Inhibit Sts 16 11-14 Step 5 Type 263 11-78 Warning Select 2 23 11-17
S-Curve Percent 47 11-21 Step 6 Speed 264 11-79 Warning Status 1 223 11-71
Scaled Spd Fdbk 63 11-24 Step 6 Value 265 11-79 Warning Status 2 224 11-72
Service Factor 9 11-11 Step 6 Type 266 11-79 Zero Speed Tol 19 11-15
Name No. Page Name No. Page Name No. Page
