Parameters 11-3
Interface/Comm Motor/Inverter
Analog Outputs
An Out 1 Value (par 105)
An Out 1 Offset (par 106)
An Out 1 Scale (par 107)
An Out 2 Value (par 108)
An Out 2 Offset (par 109)
An Out 2 Scale (par 110)
mA Out Value (par 111)
mA Out Offset (par 112)
mA Out Scale (par 113)
Digital Config
L Option Mode (par 116)
L Option In Sts (par 117)
Relay Config 1 (par 114)
Relay Setpoint 1 (par 115)
Relay Config 2 (par 187)
Relay Setpoint 2 (par 188)
Relay Config 3 (par 189)
Relay Setpoint 3 (par 190)
Relay Config 4 (par 191)
Relay Setpoint 4 (par 192)
Mop Increment (par 118)
Mop Value (par 119)
Pulse In PPR (par 120)
Pulse In Scale (par 121)
Pulse In Offset (par 122)
Pulse In Value (par 123)
SCANport Status
Dir/Ref Owner (par 128)
Start/Stop Owner (par 129)
Jog1/Jog2 Owner (par 130)
Ramp/ClFlt Owner (par 131)
Flux/Trim Owner (par 132)
Motor Constants
Stator Resistnce (par 166)
Leak Inductance (par 167)
Flux Current (par 168)
Slip Gain (par 169)
Motor Poles (par 7)
Inverter
PWM Frequency (par 10)
Inverter Amps (par 11)
Inverter Volts (par 12)
Encoder Data
Encoder PPR (par 8)
Motor Nameplate
Nameplate HP (par 2)
Nameplate RPM (par 3)
Nameplate Amps (par 4)
Nameplate Volts (par 5)
Nameplate Hz (par 6)
Motor Poles (par 7)
Service Factor (par 9)
Analog Inputs
An In 1 Value (par 96)
An In 1 Offset (par 97)
An In 1 Scale (par 98)
An In 1 Filter (par 182)
An In 2 Value (par 99)
An In 2 Offset (par 100)
An In 2 Scale (par 101)
An In 2 Filter (par 183)
mA In Value (par 102)
mA In Offset (par 103)
mA In Scale (par 104)
mA Input Filter (par 184)
SCANport Config
SP 2 Wire Enable (par 181)
SP Enable Mask (par 124)
Dir/Ref Mask (par 125)
Start/Jog Mask (par 126)
Clr Flt/Res Mask (par 127)
Gateway Data In
Data In A1 (par 140)
Data In A2 (par 141)
Data In B1 (par 142)
Data In B2 (par 143)
Data In C1 (par 144)
Data In C2 (par 145)
Data In D1 (par 146)
Data In D2 (par 147)
SCANport Analog
SP An In1 Select (par 133)
SP An In1 Value (par 134)
SP An In1 Scale (par 135)
SP An In2 Select (par 136)
SP An In2 Value (par 137)
SP An In2 Scale (par 138)
SP An Output (par 139)
Gateway Data Out
Data Out A1 (par 148)
Data Out A2 (par 149)
Data Out B1 (par 150)
Data Out B2 (par 151)
Data Out C1 (par 152)
Data Out C2 (par 153)
Data Out D1 (par 154)
Data Out D2 (par 155)
