Chapter 11
Parameters
Chapter Objectives Chapter 11 provides the information about the parameters that you
can use to program the 1336 IMPACT drive.
Important: When you change the value of a parameter, the value is
automatically stored.
Understanding the Parameter
Files and Groups
Parameters are divided into seven files to help ease programming and
operator access. These files are divided into groups, and each
parameter is an element in a specific group. Parameters may be used
as elements in more than one group.
You can also view the parameters in a linear mode. This lets you view
the entire parameter table in numerical order. You can access the
linear mode from the bottom of any group.
The following tables list the parameters that are available in each file
and group.
This topic: Starts on page:
The parameter files and groups 11-1
A numerical listing of the parameters 11-5
An alphabetical listing of the parameters 11-7
The conventions used to describe the parameters 11-9
Descriptions of the parameters 11-9
