1-6 Overview
Figure 1.2
Control Board for All Other Frames
Where Do I Go From Here? The installation and mounting instructions for your 1336 IMPACT
drive are provided in Chapter 2, Mounting and Wiring Your 1336
IMPACT Drive. Some information is frame specific. For frame-
specific information, refer to the appropriate chapter:
Gateway Connector
SCANport 1
SCANport 2
TB11TB10
L Option
Connectors
Pulse Input
Jumper (J4)
EE Jumper
Language
Module
Spares
If your drive frame reference is: Then go to:
A1, A2, A3, or A4 Chapter 3
B, C, D, E, F, G, or H Chapter 4
