1-4 Overview
What is a Frame Designator? Allen-Bradley uses frame designators to identify the various sizes of
drives. Throughout this manual, the frame sizes are frequently
referred to instead of the kW or horsepower rating.
The following frame sizes are currently available for the
1336 IMPACT drive:
Once you have determined your frame reference, write it here:____
You can disregard information that is specific to other frame
references.
If your drive falls into this three-phase drive rating
1
:
1 kW and hp are constant torque.
Then your frame
reference is:
200 – 240V 380 – 480V 500 – 600V
0.37 – 0.75 kW
0.5 – 1 hp
0.37 – 1.2 kW
0.5 – 1.5 hp
— A1
1.2 – 1.5 kW
1.5 – 2 hp
1.5 – 2.2 kW
2 – 3 hp
— A2
2.2 – 3.7 kW
3 – 5 hp
3.7 kW
5 hp
— A3
—
5.5 – 7.5 kW
7.5 – 10 hp
0.75 – 3.7 kW
1 – 10 hp
A4
5.5 – 11 kW
7.5 – 15 hp
5.5 – 22 kW
15 – 30 hp
5.5 – 15 kW
15 – 20 hp
B
15 – 22 kW
20 – 30 hp
30 – 45 kW
40 – 60 hp
18.5 – 45 kW
25 – 60 hp
C
30 – 45 kW
40 – 60 hp
45 – 112 kW
60 – 150 hp
56 – 93 kW
75 – 125 hp
D
56 – 75 kW
75 – 125 hp
112 – 187 kW
150 – 250 hp
112 – 224 kW
150 – 300 hp
E
—
224 – 336 kW
300 – 450 hp
— F
—
224 – 448 kW
300 – 600 hp
224 – 448 kW
300 – 600 hp
G
—
522 – 597 kW
700 – 800 hp
522 – 597 kW
700 – 800 hp
H
